The Superconducting Magnetic Properties of YBCO Effect on the Inductance of Coil

Abstract:

The effect of the magnetic properties of YBCO superconductors on the inductance of coil were studied in order to the dependence on temperature of effective penetration depth and the variation potential difference for damped oscillation in RLC series circuit. In this work, The samples of YBa2Cu3-xAgxO7- were prepared by solid state reaction in air at 950 ๐C for 24 hr. serves as the core of solenoids. The inductance of solenoids changes up with the increasing of temperature from boiling point of liquid nitrogen (77 K) to room temperature had been measured. Then we calculated to the effective penetration depth. We found that there were increase correspond with the increasing of temperature and the critical temperature decreased and then increased with the increase in Ag2O concentration of x = 0.1 and 0.2 , respectively. The variation potential difference for damped oscillation in RLC series circuit. We found that the decreasing of amplitude per cycle of the samples at superconducting state larger than those at normal state and phases shift in the damping oscillattion of RLC circuit at superconducting state are less than that at normal state, discussed as in inductance, the magnetic flux entering through the samples at superconducting state are less than that at normal state.

• Periodical: Advanced Materials Research (Volumes 93-94)
• Pages: 668-671
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.93-94.668
• Online since: January 2010
• Authors: Pipat Chuamuangphan, C. Chuamuangphan, Kamchai Treechairusme
• Keywords: Effective Penetration Depth, Inductance, Superconductor, YBCO

References

[1] Buckel, Werner, and Reinhold Kleiner. 2004 Superconductivity : Fundamentals and Applications. 2nd ed. Weinheim : Wiley-VCH.

[2] Huebener, R.P. 2001 Magnetic Flux Structures in Superconductors. 2 nd ed. Berlin : Springer.

[3] Schawlow, A.L., and G.E. Devlin. 1959 Effect of the Energy Gap on the Penetration Depth of Superconductors, Physical Review. Vol. 113, 1959, pp.120-126.

DOI: 10.1103/physrev.113.120

[4] Kittel, Charles. 2005 Introduction to solid state physics. 8 th ed. Hoboken, N.J. : John Wiley.

[5] Rose-Innes, A.C., and E.H. Rhoderick. 1980 Introduction to superconductivity. 2 nd ed. Oxford : Pergamon Press.
