Design, Constructand Performance Evaluation of a 2-Stage Parabolic through Solar Concentrator in Pathumthani

Abstract:

This research presents the design, construct and performance evaluation of a 2-stage parabolic trough solar concentrator (2-stage PTC). The primary stage was constructed of polished stainless steel (SUS 400) to form the primary stage parabolic reflector (1.489 m ×1.489 m size), the second stage was constructed of multi piece mirror to form the hyperbolic shape reflector (0.13 m×1.489 m). Black painted copper pipe in the size of inside diameters (27.2 mm) covered with glass tube was used as receiver. One axis Sun tracking system has been installed to track 2-stage PTC according to the direction of beam propagation of solar radiation. By using water as a heat transfer fluid its capability to heat transfer and load high temperature (100°C). The storage tank is fabricated with stainless steel of size 40 L. The experimental tests have been carried out in Faculty of Industrial Technology, Vallaya Alongkorn Rajabhat University Pathum Thani, Thailand climatic conditions (14.134°N, 100.611°E) during 5 selected days of the months May 2013. The performance of a 2-stage PTC was evaluated using outdoor experimental measurements including the useful heat gain, the thermal instantaneous efficiency and the energy gained by the water. The experimental results shown the maximum thermal efficiency was 23.43%, the optical efficiency was 76%, and the total geometrical concentration was 27.08X.

• Periodical: Advanced Materials Research (Volumes 931-932)
• Pages: 1291-1297
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.931-932.1291
• Online since: May 2014
• Authors: Krissadang Sookramoon*
• Keywords: 2-Stage Parabolic through Solar Concentrator, Concentrator Efficiency, Solar Energy

References

[1] Information on http: /weben. dede. go. th/webmax/content/areas-solar-power-potential.

[2] Martin Brunotte, Adolf Goetzbergerand Ulf Blieske, Doubling the concentration of one-axis tracking parabolic trough collectors by a new second-stage design, Proc. SPIE v. 2255 (1994) Germany.

DOI: 10.1117/12.185399

[3] R. Bader, P. Haueter, R. Bader, P. Haueter, and A. Steinfeld, Optical Design of a NovelTwo-Stage Solar Trough Concentrator Based on PneumaticPolymeric Structures, Journal of Solar Energy Engineering ASME (2009) V. 131 / 031007-1.

DOI: 10.1115/1.3142824

[4] Muriel Alaphilippe, Sébastien Bonnetand Pascal Stouffs, Low Power Thermodynamic Solar Energy Conversion: Coupling of a Parabolic Trough Concentrator and an Ericsson Engine, Journal of Thermodynamics ISSN 1301-9724 V. 10 37-45.

[5] D. Feuermann and J. M. Gordon, Analysis of a Two-Stage Linear Fresnel Reflector Solar Concentrator. J. Sol. Energy Eng. (1991) V. 113 (4) 272-279.

DOI: 10.1115/1.2929973

[6] M. Collares-Pereira, J.M. Gordon and A. Rabl, R. Winston High, concentration two-stage optics for parabolic trough solar collectors with tubular absorber and large rim angle. (1991) Solar Energy V. 47 Issue 6457–466.

DOI: 10.1016/0038-092x(91)90114-c

[7] Pablo Benítez, Rafael García and Juan C. Miñano. Contactless efficient two-stage solar concentrator for tubular absorber. Journal of Applied Optics, Vol. 36 Issue 28 (1997) 7119-7124.

DOI: 10.1364/ao.36.007119
