Push-Mode Printhead Using Magnetic Linear Actuator

Abstract:

A magnetic linear actuator drop-on-demand printhead with interchangeable components is designed and fabricated. The manufacturing processes of all parts are carried out with simple techniques. A droplet generation relies on a linear motion from a piston inside a printhead chamber that causes a pressure wave to push an ink out from a nozzle-aperture. The motion is actuated by a voice coil liked actuator. The voltage applied across the actuator is significantly lower than the piezo actuator. The interchangeable components enable rapid configuration of a printhead to suit wide range of ink-materials. The prototype of our printhead was tested with inks prepared from glycerin-water solutions. The operability of the printhead was evaluated at actuated time ranging from 2 100 milliseconds. Our printhead was able to jet a single droplet of ink with viscosity up to 35 mPa.s. The drop size is comparable to other types of printheads.

• Periodical: Advanced Materials Research (Volumes 931-932)
• Pages: 1280-1284
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.931-932.1280
• Online since: May 2014
• Authors: Mana Saedan*, Manatpong Mangkrai
• Keywords: Droplet Generator, Drop-on-Demand, Magnetic Actuator, Printhead, Push-Mode

References

[1] K. W. Binder, A. J. Allen, J. Y. James and A. Atala, Drop-on-Demand Inkjet Bioprinting: A Primer, Gene Therapy and Regulation 6 (2001) 30-49.

DOI: 10.1142/s1568558611000258

[2] J. Brunahl and A. M. Grishin, Piezoelectric shear mode drop-on-demand inkjet actuator, Sensor and Actuator A: Physical 101 (2002) 371-382.

DOI: 10.1016/s0924-4247(02)00212-1

[3] K. C. Fan, J. Y. Chen, C. H. Wang and W. C. Pan, Development of a drop-on-demand droplet generator for one-drop-fill technology, Sensors and Actuators A: Physical 147 (2008) 649–655.

DOI: 10.1016/j.sna.2008.03.006

[4] E. Li, Q. Xua, J. Sun, J. W. Y. Fuh and S. Thoroddsen, Design and fabrication of a PET/PTFE-based piezoelectric squeeze mode drop-on-demand inkjet printhead with interchangeable nozzle, Sensors and Actuators A: Physical 163 (2010) 315–322.

DOI: 10.1016/j.sna.2010.07.014

[5] S. Cheng and S. Chandra, A pneumatic droplet-on-demand generator, Experiments in Fluid 34 (2003) 755-762.

DOI: 10.1007/s00348-003-0629-6

[6] H. Sohn and D. Yang, Drop-on-demand deposition of superheated metal droplets for selective infiltration manufacturing, Materials Science and Engineering A 392 (2005) 415–421.

DOI: 10.1016/j.msea.2004.09.049

[7] J. M. McBean, Design and Control of a Voice Coil Actuated Robot Arm for Human-Robot Interaction, Massachusetts Institute of Technology, (2004).

[8] E. R. Lee, Fabricating Tapered Profile Glass Nozzles, in Microdrop Generation, CRC Press LLC, 2003, pp.113-114.

[9] N. S. Cheng, Formula for Viscosity of Glycerol-Water Mixture, Industrial and Engineering Chemistry Research 47 (2008) 3285-3288.

DOI: 10.1021/ie071349z
