Design and Prototyping of a Fuel Cell Controlling Equipment for Small Hybrid Driving Airship System

Abstract:

In the present study, an airship for the fixed point observation of nara withering in village forests was designed and trial manufactured. The airship consists of a helium gas filling envelope of 4.5m in total length, propeller-driven motors, a polymer electrolyte fuel cell (PEFC) in order to achieve longer flight, Ni-H batteries, a CCD camera observation system, and propeller control systems. Automatic charging device was designed to charge the Ni-H battery from the PEFC in the sky automatically. It controlls the power system by using a micro computer in a mannar where the electromagnetic valve supplying hydrogen is open to recover the output voltage of the PEFC when the voltage of Ni-H battery decreased to a certain level, resulting in energy charging to the Ni-H battery and keeping the rotation of the moter. The opened electromagnetic valve is closed when the Ni-H battery full charged. Furthermore, after a certain hours operation when the output voltahge of the PEFC drops due to accumulation of impurities in hydrogen gas, the outlet valve will be opened to exhaust hydrogen containing accumulated impurities. It has been verified that as soon as the Ni-H battery voltage doropped to less than 3.8 [, the hydrogen inlet valve opened then the output of the power source increased suddnly to around 7 [.

• Periodical: Advanced Materials Research (Volume 933)
• Pages: 444-449
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.933.444
• Online since: May 2014
• Authors: Toshiro Kobayashi*, Masahiro Fukushima, Hideyuki Kanematsu, Yuichi Utsumi, Yoshiaki Shimamoto
• Keywords: Airship, Battery, Controll, Fuel Cell (FC), Micro Computer, PEFC

References

[1] Y. Katsuyama, Y. Ohba, Integrated Tracking and Control System for Stratospheric Platform, Toshiba Review, Vol. 60 No. 11（2005）, pp.7-11. (in Japanese).

[2] S. Maekawa, M. Nakadate, On the structure of the low altitude stationary flight test vehicle, Journal of Aircraft, Vol. 44, No. 2 (2007), pp.882-666.

DOI: 10.2514/1.25044

[3] http: /www. spc. jst. go. jp/hottopics/1110space , _science/r1110_ton. html.

[4] http: /yama-sone. at. webry. info/200908/article_9. html.

[5] T. Kobayashi, J. Gotoh, T. Fukuda and H. Kanematsu, Design and Trial manufacturing of an Airship equipped with Fuel Cell Hybrid driving system, 2012. 11 2nd Japan-Thailand Friendship International Workshop on Science, Technology & Education (JTSTE 2012), Nov. 15-16th, (2012).

[6] D. Ragone, Review of Battery Systems for Electrically Powered Vehicles, SAE Technical Paper 680453, 1968, doi: 10. 4271/680453.

DOI: 10.4271/680453

[7] C.Y. Chen, S. W. Hsu, W. M. Yan, W. H. Lai, K. P. Huang, C. C. Yang, C. C. Chen and M. P. Lai, Development and Diagnosis of a 1-kW Self-Sustainable Proton Exchange Membrane Fuel Cell System With a Methanol Reformer, J. Fuel Cell Sci. Technol 10(3), 031007 (May 14, 2013) (9 pages).

DOI: 10.1115/1.4024256

[8] P. Karthikeyan, M. Muthukumar, S.V. Shanmugam, P. P. Kumar, S. Murali, A. P. S. Kumar, Optimization of Operating and Design Parameters on Proton Exchange Membrane Fuel Cell by using Taguchi method, Procedia Engineering, Volume 64, 2013, p.409–418.

DOI: 10.1016/j.proeng.2013.09.114
