Numerical Simulation Analysis of the Overall Stability of Hot-Rolled H Section Steel Beam Based on ANSYS

Abstract:

Based on finite element software ANSYS, the paper analyzed the overall stability of hot-rolled H shaped section Q235 steel beams with two symmetric axis under uniformly distributed loads, compared with the current code for design of steel structures, discussed the effect of high span ratio on the results of numerical simulation. The results show that when the high span ratio is less than 30, numerical analysis method and the standard methods agree well, but when the high span ratio exceeds 30, the error is big.
