260t Ladle Stress and Deformation Finite Element Analysis

Abstract:

In this paper, iron ladle stress and deformation has been accurately calculated using finite element analysis software ANSYS based on 260t iron ladle in standing, lifting, tipping working conditions. Distribution of stress field was obtained. The stiffness and strength of the iron ladle has been evaluated. The results show that the iron ladle in the standing, lifting and tipping working conditions, structural deformation is small, the strength and stiffness meet the requirements. This research extends the working life of 260t iron ladle. It provides theoretical basis for producing and using of the iron ladle and further optimal designing.

• Periodical: Advanced Materials Research (Volume 936)
• Pages: 1886-1889
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.936.1886
• Online since: June 2014
• Authors: Yan Ping Sun*, De Chen Zhang, Ming Yang, Yuan Li
• Keywords: Deformation, Finite Element Method (FEM), Iron Ladle, Stress

References

[1] Qianglong Zhang, Naiyuan Tian. Ladle multi-functional technology, Beijing University of Science and Technology. 2007, (4) : 424-427.

[2] Daliang Shi. Ladle design quick calculation method. Chinese casting machine. 1994, (3) : 15-18.

[3] Renxi Hu, Shiting Kang, Cunhong Lu. Solid Chinese board in the Works 2008 Standard instance tutorial Mechanical Industrial Press . 2009: 69-89.

[4] Shihui Li, Furong Chen. element analysis of stress field of the ladle. Steelmaking. 2007, 23 (3): 62-37.

[5] Zhihua Chen. 150Tladle three-dimensional mechanical stress and deformation analysis of metallurgical equipment . 2010, (1): 41-43.

[6] Saeed Moaveni. Finite Element Analysis Theory and Application ANSYS, Third Edition. Electronic Industry Press, Beijing. 2008: 493-522.
