Research of Power-On Detection in POE Topology

Abstract:

POE (Power Over Ethernet) realizes the multiplexing of power transmission and data transmission. To ensure the safety of power supply process, PD (Powered Device), when connected, must be detected by PSE (Power Sourcing Equipment). This article describes the methods of PD detection especially in the symmetrical architecture. The symmetrical architecture means that PSE and PD are connected and either of them can play a role of PSE or PD. In our new approach, signature resistance is replaced by signature capacitance. The connection of PD changes the capacitance load of the system, so the step response can be used to detect the change of capacitance load. This method requires zero static current, which reduces the system power consumption. The theoretical analysis, PSPICE simulation and the experimental results are given.

• Periodical: Advanced Materials Research (Volume 936)
• Pages: 2196-2200
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.936.2196
• Online since: June 2014
• Authors: Zhao Han*, Jie Wu, Qing Yun Dong, Ke Ren, Juan Dong
• Keywords: Connection Detect, POE, Signature Resistance, Step Response, Symmetrical Architecture

References

[1] IEEE 802. 3af Data Terminal Equipment (DTE) Power via Media Dependant Interface (MDI) [S]: IEEE Computer Society, (2003).

[2] Freescale Semiconductor Inc. MC34670 IEEE 802. 3af PD With Current Mode Switching Regulator [R] USA: Freescale Semiconductor Inc. (2006).

[3] Linear Technology Corporation LTC4259A Quad IEEE 802. 3af Power over Ethernet Controller with AC Disconnect [R] USA: Linear Technology Corporation, (2004).

[4] Power over Ethernet. IEEE 802. 3af White Paper. http: /belden. com/docs/upload/PoE_Basics_WP. pdf.

[5] Anon. Power over Ethernet. Electronic Design, 2004(4): 9~17.

[6] Morrison, David G. Power-over-Ethernet chips give LANs a new outlet. Electronic Design, 2003(10): 51~62.
