The Application of HPWM in Improving Vehicle Lateral Stability

Abstract:

The application of the High-frequency pulse width modulation (HPWM) for improving vehicle lateral stability is investigated in the paper. Firstly, a hydraulic control unit (HCU) combined with a high-speed switching valve (HSV) for controlling hydraulic oil pressure by adjusting duty cycle is presented. Then, a typical control strategy is described based on the application of HPWM. Finally, by using a 15dofs vehicle model, a simulation is carried out to investigate the role of HPWM on improving vehicle lateral stability. The results show that HPWM is capable to control the output pressure of HSV accurately and improve vehicle lateral stability effectively.

• Periodical: Advanced Materials Research (Volume 936)
• Pages: 2171-2176
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.936.2171
• Online since: June 2014
• Authors: An Jing Zhang*, Yan Hai Xu, Xin Lv
• Keywords: High-Speed Switching Valve, HPWM, Hydraulic Control Unit, Vehicle Lateral Stability

References

[1] Liangmo Wang, Li Tan, Li-hua An, et al; Study on the ESP System Based on Fuzzy Logic PID Control and Multibody Dynamics, J. Electrical Systems, 2012, 8(1): 57-75.

[2] Yang Cai, Song Jian. A Research on Algorithms for Calculating Vehicle Reference Speed and Slip Ratio in ABS/TCS/AYC Systems, J. Automotive Engineering, 2009, 31(1): 24-27.

[3] Yu Zhuoping, Gao Xiaojie. Review of Vehicle State Estimation Problem under Driving Situation, J. Journal of Mechanical Engineering, 2009, 45(5): 20-32.

DOI: 10.3901/jme.2009.05.020

[4] Qi Xue 1e，Song Jian，Wang Huiyi，et al. Modeling and Analysis of Vehicle ESP Hydraulic Control Device Using AMESim, J. Machine Tool & Hydraulics，2008, 8: 115-116.

[5] Wang Weiwei, Song Jian, Li Liang, et al. High speed on-off solenoid valve with proportional control based on high frequency PWM control, J. Journal of Tsinghua University, 2011, 51(5): 715-719.
