Design of the Hydraulic System of Lead Plate Coiling Machine

Abstract:

This paper mainly introduces the process of lead electrolysis, the structure and working principle of lead plate coiling machine and Its’ parts, coiling machine components. First of all, rewind section hydraulic system adopts a return to the oil throttle speed control, it is stable and can bear a certain change load, can overcome the stage before the tension fluctuation of the impaction to the rotation speed of hydraulic motor. Secondly, speed and tension control system adopt electro-hydraulic servo valve and proportional relief valve are respectively to the drum speed and output torque control,it has high precision and accurate in speed and tension control. contact coiling section use electro hydraulic servo position control system with close loop control to improve the accuracy of position control. Finally, calculate parameters of each working section of hydraulic control system , verify the hydraulic component model and the rationality of the hydraulic circuit.

• Periodical: Advanced Materials Research (Volume 937)
• Pages: 336-340
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.937.336
• Online since: May 2014
• Authors: Hui Sen, Rui Bo Yuan*, Rong Li
• Keywords: Coiling Machine, Hydraulic, Lead Plate

References

[1] Nonferrous metal smelting equipment editorial board. Non-ferrous metal smelting equipment (First Edition). Smelting equipment. Beijing: Metallurgical Industry Press, (1993).

[2] Liu Sen. Electro hydraulic proportional control on lead cathode stepping conveyor application research [Master thesis]. Kunming, Kunming University of Science and Technology, 2011(In Chinese).
