Study on Inspection Methods for High-Speed Progressive-Die Punched Strips

Abstract:

The inspection of sheet strips post high-speed punching mainly relies on the manual off-line inspection with basic inspection equipment or CCD equipment. Such inspections cannot reflect the real-time conformity of strip machining, and in severe cases, lead to rejects in batches, causing a tremendous waste in production. Now that the application of charge-coupled device (CCD) technology in product inspection is relatively mature, it would be a very good thought to adopt the CCD technology to realize real-time online inspection of conformity of the high-speed punched strips. KeyWords: CCD technology; strip; online automatic inspection; progressive die

• Periodical: Advanced Materials Research (Volume 940)
• Pages: 69-73
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.940.69
• Online since: June 2014
• Authors: Zheng Ping Hai*, Zhi Hong Yang, Jian Hua Ning
• Keywords: CCD Technology, Online Automatic Inspection, Progressive Die, Strip

References

[1] Yao Qijun. A Course in Optics , 1st edition, Higher Education Press Beijing, (1996).

[2] Kundu A and Zhou J. Combine Median Fiiter, IEEE Trans on image Processing 1992(1): 3.

[3] Ruikang Yang. Optimal Weighed Median Filtering Under Structural Constraints, IEEE transactions on signal processing, 1995(3): 591-603.

DOI: 10.1109/78.370615

[4] M.Z. Brown.D. Burschka. Advances in computational stereo, IEEE Transactions on Pattern Analysis and Machine Intelligence, 2003, 25(8): 993~1008.

DOI: 10.1109/tpami.2003.1217603
