Optimization Design of Evaporator Tube Plate Mold Based on PDX

Abstract:

Current tube plate stamping die usually have some common problems, which include low standardization, low standard penetration and long mold design cycle. By analyzing stamping die used in the refrigeration industry, the cold-drawing dies blanking needs to be designed and optimized. Compared with the previous design methods, the method, that the Pro/E plug-PDX was used to design cold-drawing dies blanking with refrigeration equipment, has a lot of advantages. First, cycle was shortened to one-third of the original; second, the compound pressing method is able to reduce the pressing step and increase stripping device, in order to improve the reasonable structure and production efficiency. The new method proposed in this paper is able to increase design efficiency, shorten design cycles, reduce workload and improve the accuracy of the mold design, and reduce the cost of mold design.

• Periodical: Advanced Materials Research (Volumes 941-944)
• Pages: 1752-1756
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.941-944.1752
• Online since: June 2014
• Authors: Zhang Yu Gao*, Hui Chen, Yan Jie Zhang, Shi Nan Li, Hong Mei Yu, Wei Xu, Lu Ning Yu
• Keywords: Cold-Blanking Stretch, Evaporator Tube Plate Mold, Mould Design, Plug-in of Pro/E-PDX

References

[1] Zhao Hui, Chen Jingliang, etc. Refrigeration and Air Conditioning, pp.1-5(2013) . In Chinese.

[2] Fu Hongsheng , cold stamping process and die design and manufacturing, Beijing Chemical Industry Press, (2005). In Chinese.

[3] Li Chenglong, Ge Zhenghao, etc, mechanical design and manufacturing, pp.189-190(2007). In Chinese.

[4] Wang Yun. Pro/ENGINEER wildfire 5. 0 tutorial examples stamping die design, National Defense Industry Press , 2012. In Chinese.

[5] Qin Zhipan, Zhang Huaicun . Research on Pro / E stamping automation system based on plate [J], mechanical design and manufacturing, 2008 . In Chinese.
