Signal Acquisition and Analysis of Shaft Unbalance Vibration Test

Abstract:

This paper simulated the unbalance vibration conditions by the vibration test platform, measuring some common characteristic parameters of unbalance vibration fault diagnosis. This paper chose the time-domain analysis method, processing the characteristic parameters of the test, so as to achieve the purpose of vibration diagnosis. Through a large number of experimental data, this paper verified the feasibility and the effectiveness of the proposed approach to the unbalance fault diagnosis. The method proposed in this paper not only can be applied to unbalance fault diagnosis, but also can be promoted to apply to the fault diagnosis of other rotating machinery.

• Periodical: Advanced Materials Research (Volumes 945-949)
• Pages: 1090-1093
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.945-949.1090
• Online since: June 2014
• Authors: Hai Peng Zhang*, Hong Wu Chen, Bin Hu, Cheng Tian
• Keywords: Axial Unbalanced Vibration, Fault Diagnosis, Symptom Parameter, Time Domain Analysis Method

References

[1] Guyan R J. Reduction of stiffness and mass matrices[J]. AIAA Journal，1965，3（2）：380.

[2] Jia Qu, etc. The failure analysis of rotating machinery loose[J]. Chinese Equipment Engineering, 2010 (9): 59-60.

[3] Dunhuang Pu, etc. The identification of the vibration main transmission path [J]. Vibration Engineering, 1989, 2(1): 32-38.

[4] Fangze Li, etc. Testing and analysis of Engineering Vibration[M]. Beijing: Higher Education Press, 1992 (8).

[5] Peng Chen, etc. Operation of mechanical fault diagnosis[J]. Journal of mechanical engineering，2001（12）: 32-34.
