Shock-Resistance Research of Ship Structural Subjected to Underwater Explosion

Abstract:

A finite element model ships, for example design test condition of the underwater explosion, selection of explosive package quantity is 1000KG TNT, the explosive location along the direction of the ship with the bow, midship and stern, the angle of attack in three exploded cross section have 90 degrees, 60 degrees, 45 degrees, 30 degrees and 0 degrees. According to the current standard to calculate the ship damage radius, critical radius and safety radius of specific values under the effect of underwater explosion, interpolation calculation and draw the envelope. Analysis shows that the vitality of ships and shock-resistance is not only related to the explosive distance, also related to the attack position.

• Periodical: Advanced Materials Research (Volumes 945-949)
• Pages: 1180-1184
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.945-949.1180
• Online since: June 2014
• Authors: Yao Guo Xie
• Keywords: Ship Structure, Shock-Resistance, Underwater Explosion

References

[1] Yu. Wang: Modern Ship Anti-shock Theory and Applications (Science Press, China 2005).

[2] GJB 4000-2000, General Specifications for Naval Ships.

[3] Xi. Zhu, Zhenhua. Zhang: Explosion and Shock Waves. Forum Vol. 24 (2004), pp.541-545.

[4] Geers,  T. L., and K. S. Hunter: Journal of the Acoustical Society of America, Forum Vol. 111(2002), p.1584–1601.

[5] Yi. Wu, Yongle. Li: Application of Mathematical Statistics (National University of Defense Technology Press, China 2001).
