Rigid Joints Transferring Forces outside Box Columns with Deviation of Column's Verticality - Finite Element Method Simulation

Abstract:

Three groups of specimens were designed in this paper to compare the performance of rigid joints transferring forces outside box columns to that of traditional joints by finite element method program ANSYS. The influences of deviation of verticality in columns on stiffness, yielding capacity, and ultimate carrying capacity were analyzed. The evaluation of working performance by adding force-transforming plates could be found. The thickness and width of adding plates would be the key parameters of steel frame joints. This paper put forward the optimal range of design parameters.

You might also be interested in these eBooks

Advances in Manufacturing Science and Engineering V

View Preview

Info:

Periodical:

Advanced Materials Research (Volumes 945-949)

Pages:

1201-1206

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.945-949.1201

Citation:

Cite this paper

Online since:

June 2014

Authors:

Guang Xian Liang*, Zhong Gen Xu, Wei Ming Chen, Chang Gen Deng

Keywords:

Carrying Capacity, Force-Transforming Plates, Joint, Verticality

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] SHI Yong-jiu, WANG Meng, WANG Yuan-qing. Analysis on seismic behavior of overall steel frame with different welded connection constructions [J]. Engineering mechanics, 2012, 29(11): 71-79 (in Chinese).

Google Scholar

[2] Pachoumis, D. T., Galoussis, E. G. Kalfas, C. N. and Efthimiou, I. Z., Cyclic performance of steel moment-resisting connections with reduced beam sections-experimental analysis and finite element model simulation[J]. Engineering structures, 2010, 32: 2683-2692.

DOI: 10.1016/j.engstruct.2010.04.038

Google Scholar

[3] Dingrong Cheng. Experiment and analysis of connection of steel frames rectangular tube column without inner plates [D]. Guangzhou University, 2012 (in Chinese).

Google Scholar

[4] Z.G. Xu, D.R. Cheng, C.G. Deng. Fem-Analysis of Beam-Column Rigid Joints Transferring Forces Outside Box Columns [J]. Proceedings of Seventh International Conference on Advances in Steel Structures: 502-509.

Google Scholar

[5] GB50205-2001, Code for acceptance of construction quality of steel structures,. Beijing: China planning Press. 2001 (in Chinese).

Google Scholar
