The Modal Analysis with Finite Element Method for Body Section of EBZ160 Roadheader

Abstract:

Body section is the main part of the roadheader and its stability had serious impact on the working efficiency and the stability of roadheader. It is under all the dynamic impact from the other parts of roadheader. Since complex force condition, violent and irregular vibration, the stability of body section is particularly important and the mechanical parts design plays very important roll to the EBZ160 Roadheader. The paper gets the vibration modes, maximum amplitudes of the body section and where they appear by modal analysis of two main parts of the body section whose maximum order is five. According to the result, more attention must be paid to the complex force condition, violent and irregular vibration of the body section in the design.

• Periodical: Advanced Materials Research (Volumes 945-949)
• Pages: 1207-1210
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.945-949.1207
• Online since: June 2014
• Authors: Zhi Feng Dong, Li Yu Fang*, Gong Dan, Chuan Feng Deng
• Keywords: Body Section, Finite Element, Modal Analysis, Roadheader

References

[1] Ping Ma. Technology Develop for Lateral Axis Roadheader of EBZ Series. Coal Technology, In Chinese , 2006(10).

[2] Jun Mao, Wu Changtian, Xie miao. The Development and Tendency of Roadheader. Chinese Journal of Engineering Machinery, In Chinese , 2007(2).

[3] Zhihong Lun. The Research on Welding Procedure for Body Section of Roadheader. Technology and Company, In Chinese , 2013 (10).
