Research on Sterotype Kettle Screw Error Compensation

Abstract:

In order to solve the position inaccuracy when parking the kettle net car, we studied the compensation method of the screw rotation .The reason of the error has been found by analyzing the setting position and the actual position of the screw during transmission process. The enlargement process was added into the PLC data block and a sent pulse formula which was of the screw error compensation was deduced based on the test data .The test result showed that the screw drive error can be controlled within the specified range effectively and that the net car would park in the setting location by this way.

• Periodical: Advanced Materials Research (Volumes 945-949)
• Pages: 1569-1572
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.945-949.1569
• Online since: June 2014
• Authors: Xiang Lin Chen*
• Keywords: Control, Error Compensation, PLC, Screw, Stereotypes Kettle

References

[1] Yuxiang Guan. 《The Machining Error and Control》[M]. Beijing: Machine Press, 1994. 05, Version 1 ( In Chinese).

[2] Kangxiong Wu, Lang Hu: Journal of Changsha University of Science and Technology (Natural Science) , 2013. 3, pp.77-81( In Chinese).

[3] Manlong Chen: Journal of Mechanical Transmission, 2008（32）, pp.98-100( In Chinese).

[4] Genggeng YANG, Peiqing YE, Kaiming YANG, Huayun YOU: Modular Machine Tool & Automatic Manufacturing Technique, 2002（6）, pp.4-5, 34( In Chinese).

[5] Ju LI 1, Huiping SHEN 1, Yixin JIANG 1, Xiaodong XU 2, Wei XU 2, Kai WANG 2: JOURNAL OFMACHINE DESIGN, 2009. 4（26）, pp.59-61( In Chinese).
