Hydraulic Control System Design for XYZM Plate-and-Frame Filter Press

Abstract:

This paper introduces the working principle of XYZM Plate-and-frame Filter Press, illustrates the working process of the hydraulic control system by combining circuit and hydraulic principle diagram, and then gives out the checking analysis and the failure analysis on the hydraulic system. The application results show that our hydraulic control system can not only complete the automatic control well for the plate-and-frame filter press, but also keep the pressure stable and controllable, which improves the productivity and the system effectiveness.

You might also be interested in these eBooks

Advances in Manufacturing Science and Engineering V

View Preview

Info:

Periodical:

Advanced Materials Research (Volumes 945-949)

Pages:

2788-2793

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.945-949.2788

Citation:

Cite this paper

Online since:

June 2014

Authors:

Lan Xiang Hou*, Feng Gang Li, Cai Xia Ju, Wei Xu

Keywords:

Hydraulic Control System, Liquid-Solid Separation, Plate-and-Frame Filter Press
