The Deformation Characteristics of Hydro-Forming of Differential Gear Box for Automobile

Abstract:

The hydroforming process of differential gear box for automobile under axial compressive load and internal bulging pressure was simulated and the load paths were optimized. The hydroforming process is divided into two steps. The deformation under different load paths was investigated using dynamic explicit finite element method. The distribution of equivalent strain and thickness was investigated as well. The simulation results show that the forming path for the first step is optimal when internal pressure changes linearly from 37MPa to 65MPa with the axial displacement.

• Periodical: Advanced Materials Research (Volumes 945-949)
• Pages: 880-884
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.945-949.880
• Online since: June 2014
• Authors: Wen Huang*, Hai Bo Yu, Hong Lu, Si Ji Qin
• Keywords: Differential Gear Box, Formability, Hydroforming, Nonlinear FEM, Numerical Simulation

References

[1] Wang Tonghai: Tube plastic processing technology(Mechanical Industry Press, Beijing 1998) (in Chinese).

[2] Dohmann F. and Hartl Ch.: Tube Hydroforming-research and Practical Application. Journal of Materials Processing Technology, 1997, 71(1): 174~186.

DOI: 10.1016/s0924-0136(97)00166-0

[3] Terumori Ueda: Differential Gear Casting for Automobiles by Liquid Bulge Forming Process-Part 1. Sheet Metal lndustries, 1983, 60(3): 181~185.

[4] Terumori Ueda: Differential Gear Casting for Automobiles by Liquid Bulge Forming Process-Part 2. Sheet Metal Industries, 1983, 60(4): 48~56.

[5] .
