Spanwise Penetration Depth with Turbine Disk Inclination

Abstract:

Spanwise penetration depth as a new correlating parameter was introduced in the cascade profile loss correlation of a new loss breakdown scheme for turbine cascade reported in the literature. For the case of an inclined turbine disk, when a turbine disk is inclined to its design position, the blade incidence or inlet flow angle varies with the position of blade on the turbine disk circumference, leading to the variation of spanwise penetration depth. To examine the influences of turbine disk inclination on the spanwise penetration depth, new correlations were developed and numerical simulations were performed with MATLAB. The role that turbine disk inclination plays in the spanwise penetration depth is manifested in a modified inlet flow angle expression on account of turbine disk inclination. It is concluded that the turbine disk inclination has considerable influences on the spanwise penetration depth in the turbine cascade passage.

• Periodical: Advanced Materials Research (Volumes 945-949)
• Pages: 887-891
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.945-949.887
• Online since: June 2014
• Authors: Zhen Wei Yuan*, Jun Zhang, Dong Shuai Zhu
• Keywords: Incidence, Profile Losses, Spanwise Penetration Depth, Turbine Cascade, Turbine Disk Inclination

References

[1] Ainley D G, and Mathieson G C R. A method of performance estimation for axial flow turbines. British Aeronautical Research Council, R and M 2974, (1951).

[2] Dunham J, and Came P M. Improvements to the Ainley-Mathieson method of turbine performance prediction. ASME Journal of Engineering for Power, 1970, 92: 252-256.

DOI: 10.1115/1.3445349

[3] Stewart W L, Whitney W J, Wong R Y. A study of boundary layer characteristics of turbomachine blade rows and their relation to overall blade loss. Transactions of the ASME, 1960, 82: 588-592.

DOI: 10.1115/1.3662671

[4] Craig H R M, and Cox H J A. Performance estimation of axial flow turbines. Proceedings Institution of Mechanical Engineers, 1971, 185(32): 407-424.

DOI: 10.1243/pime_proc_1970_185_048_02

[5] Kacker S C, and Okapuu U. A mean line prediction method for axial flow turbine efficiency. ASME Journal of Engineering for Power, 1982, 104: 111-119.

DOI: 10.1115/1.3227240

[6] Moustapha S H, Kacker S C, and Tremblay B. An improved incidence losses prediction method for turbine airfoils. ASME Journal of Turbomachinery, 1990, 112: 267-276.

DOI: 10.1115/1.2927647

[7] Mukhtarov M K, and Krichakin V I. Procedure of estimating flow section losses in axial flow turbines when calculating their characteristics. Teploenergetika, 1969, 16(7): 76-79.

[8] Benner M W, Sjolander S A, and Moustapha S H. Influence of leading-edge geometry on profile losses in turbines at off-design incidence: Experimental results and an improved correlation. ASME Journal of Turbomachinery, 1997, 119: 193-200.

DOI: 10.1115/1.2841101

[9] Benner M W, Sjolander S A, and Moustapha S H. An empirical prediction method for secondary losses in turbines—Part I: A new loss breakdown scheme and penetration depth correlation. ASME Journal of Turbomachinery, 2006, 128: 273-280.

DOI: 10.1115/1.2162593

[10] Benner M W, Sjolander S A, and Moustapha S. H. An empirical prediction method for secondary losses in turbines—Part II: A new secondary loss correlation. ASME Journal of Turbomachinery, 2006, 128: 281- 291.

DOI: 10.1115/1.2162594

[11] Sharma O P, and Butler T L. Predictions of endwall losses and secondary flows in axial turbine cascades. ASME Journal of Turbomachinery, 1987, 109: 229-236.

DOI: 10.1115/1.3262089

[12] Hodson H P, and Dominy R G. The off-design performance of a low-pressure turbine cascade. ASME Journal of Turbomachinery, 1987, 109: 201-210.

DOI: 10.1115/1.3262086

[13] Perdichizzi A, and Dossena V. Incidence angle and pitch-chord effects on secondary flows downstream of a turbine cascade. ASME Journal of Turbomachinery, 1993, 115: 383-391.

DOI: 10.1115/1.2929265
