Model Identification of Power Lithium-Ion Battery Based on Laplace Transform

Abstract:

In allusion to nonlinear characteristic of power lithium-ion battery, presented a method for identifying of power lithium-ion battery based on Laplace transform. First, analyzed the characteristics of the equivalent circuit model of power lithium-ion battery, determined the model of second-order RC equivalent circuit; Second, established equation of second-order RC equivalent circuit and conducted a Laplace transform; Third,using the massive data of charge-discharge test,model parameters was identified by least-squares method; Simulation results show that the method can effectively identify the equivalent model parameters, and model parameters small error.

• Periodical: Advanced Materials Research (Volumes 953-954)
• Pages: 775-779
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.953-954.775
• Online since: June 2014
• Authors: En Guang Hou, Xin Qiao, Guang Min Liu
• Keywords: Laplace Transform, Least-Square Method (LSM), Parameter Identification, Power Lithium-Ion Battery, Second-Order Rc Equivalent Circuit

References

[1] Jinlong Zhang, Chaoying Xia. State-of-charge estimation of valve regulated lead acid battery based on multi-state Unscented Kalman Filter [J]. Electrical Power and Energy Systems, 33 (2011) 472–476.

DOI: 10.1016/j.ijepes.2010.10.010

[2] PILLER S, PERRIN M, JOSSENA. Methods for state-of-charge determination and their applications [J]. Journal of Power Sources, 2001, 96(1): 113-120.

DOI: 10.1016/s0378-7753(01)00560-2

[3] Juzlow M W，MayerST. In: Design considerations for lithium-ion cells. Part l: Cell components. Battery Conference on Applications and Advances， 1997，189-193.

[4] Gao L J，Liu S Y，Douga R A. Dynamic lithium-ion battery model for system simulation. IEEE Transactions on Components and Packaging Technologies，2002，25(3): 495-505.

DOI: 10.1109/tcapt.2002.803653

[5] Hongwen He, Rui Xiong. State-of-Charge Estimation of the Lithium-Ion Battery Using an Adaptive Extended Kalman Filter Based on an Improved Thevenin Model [J]. IEEE TRANSACTIONS ON VEHICULAR TECHNOLOGY, VOL. 60, NO. 4, MAY 2011: 1461-1468.

DOI: 10.1109/tvt.2011.2132812

[6] Xuezhe Wei, Zechang Sun. Parameter Identification and State Estimation of Li-Ion Power Battery in Hybrid Electric Vehicle [J]. JOURNAL OF TONGJI UNIVERSITY( NATU RAL SCIENCE), 2008, 36(2)：231-235（In Chinese）.

[7] Rui Xiong, Hongwen He. Study on Identification approach of Dynamic Model Parameters for Lithium-ion Batteries Used in Hybrid Electric Vehicles [J]. Power Electronics, 2011, 45(4)：100-102 （In Chinese）.
