A Novel Shapley Solution for Power System Loss Allocation Under Hybrid Transaction Modes

Abstract:

The allocation of power system loss under hybrid transmission modes was investigated. First, a concept and method for converting a bilateral transaction into its two equivalents pool transactions were proposed. Then, a model based on Shapley value was designed to allocate the power system loss in the framework of equivalent pool transactions. The Shapley solution in cooperative game theory was employed to allocate the power system loss to each load pool transaction that includes the equivalent ones. The proposed method is applicable for electricity markets containing pool and bilateral transactions. It satisfies electric circuit laws and provides economic signals to users. The effectiveness of the proposed method is verified by the IEEE 5-bus test system.

• Periodical: Advanced Materials Research (Volumes 960-961)
• Pages: 1091-1094
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.960-961.1091
• Online since: June 2014
• Authors: Xiao Teng Wu, Li Jun Qin
• Keywords: Bilateral Transaction, Cooperate Game, Electricity Market, Pool Transaction, Power Flow, Power System Loss Allocation, Shapley Value

References

[1] B Xu, X.J. Zhang and Z.X. Ti, Loss Allocation Using Marginal Loss Coefficient Method, East China Elect. Power, vol. 01, pp.15-17, 2001. In Chinese.

[2] Z.C. Du and D.Z. Xia, The Allocation of Power System Loss, Autom. Elect. Power Syst., vol. 04, pp.18-22, 2002. In Chinese.

[3] Q.G. Wu, Z.H. Cheng and Z.H. Liu, New Regulation Method of Marginal Loss Coefficient Loss Allocation of Power Market, Proc. of Elect. Power Syst. andAutom., vol. 03, pp.78-81, 2005. In Chinese.

[4] Z.H. Liu, Z.H. Cheng and X.D. Liu, Influence of Node-injected Reactive Power on Loss Allocation in Electricity Market by Marginal Loss Coefficient Method, Power Syst. Tech. vol. 03 pp.51-54, 2004. In Chinese.

[5] G.M. Lu, Research on Losses Allocation and Generation Bidding Price Modification in Electricity Market, North China Elec. Power Univ.

[6] X Tan, T.T. Lie, Application of the Shapley value on transmission cost allocation in the competitive power market environment generation, Trans. &Dist., vol. 49, pp.15-20, (2002).

DOI: 10.1049/ip-gtd:20020005

[7] Z. Y Hu, Z.X. Han, A Shapley Value for Loss Allocation, Autom. Elect. Power Syst., vol. 07, pp.32-35, 2003. In Chinese.

[8] X.H. Zhou, S.H. Du, A Novel Nucleolus-Based Loss Allocation Methodin Bilateral Electricity Markets, Proc. of the Csee, vol. 01, pp.63-68, 2005. In Chinese.

[9] X Gao, J.C. Peng and A Luo. A Nucleolus Solution for Fixed Transmission Cost Allocation Under Hybrid Transactions Modes, Proc. of the Csee, vol. 23, pp.120-124, 2007. In Chinese.

[10] Z. Xie"Game Theory", in press.

[11] RodicaBranzei, DinkoDimitrov, StefTijs, Models of Cooperative Game Theory, in press.
