Modal Analysis of Two Wheels Scooter Based on Solidworks

Abstract:

Based on Solidworks software, the three-dimensional model of two wheels scooter is set up. The finite element model of two wheels scooter is generated. Modal analysis of driving system and telescopic mechanism of bar on two wheels scooter is investigated. The first five orders natural frequency and major modes of driving system and telescopic mechanism of bar are clarified. The method and the result can be used as a reference of dynamic design and lay foundation for calculation and analysis of dynamic response for the two wheels scooter.

• Periodical: Advanced Materials Research (Volumes 960-961)
• Pages: 1420-1423
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.960-961.1420
• Online since: June 2014
• Authors: Zhi Dong Huang*, Guo Fei Li, Juan Cong, Yun Wang, Wei Na Yu, Quan Gu
• Keywords: Finite Element Method (FEM), Modal Analysis, Natural Frequency, Scooter

References

[1] F. Zhang, X.Z. Yang and T. Li: Journal of Hubei Polytechnic University Vol. 29 (2013), pp.13-16 (In Chinese).

[2] T.X. Tian, Y.G. Hu and H.J. Shen: Mechanical Engineer No. 9 (2005), pp.59-60 (In Chinese).

[3] P.P. Liu, D.D. Zhang: Development & Innovation of Machinery & Electrical Products Vol. 22 (2009), pp.67-68 (In Chinese).

[4] Y.M. Zhang: Mechanical Vibration Dynamics(Jilin Science and Technology Press, China 2000).
