Cubic Spline Interpolation Method for the Envelope Tracking of Middle and Low Frequency Voltage Flicker

Abstract:

Flicker envelope tracking is the key of analyzing voltage flicker signal. A novel method, i.e., cubic spline interpolation method is applied in the detection of the voltage flicker envelope. The typical flicker signals, such as one or multi-frequencies and frequency time-varying flicker signal are selected and analyzed by this method. Simulation results indicate that this method is effective in the detection of the envelope of voltage flicker signal. Results of one or multi-frequencies flicker signal simulation show that, when flicker frequency is less than 15Hz , the error of this method is quite tiny. The detection precision of this method is higher, especially in the scope of low frequencies of flicker and this method makes up for the disadvantage of square demodulation. Furthermore, results of frequency time-varying flicker signal simulation show that, the occurrence and recover time of voltage flicker signal can be accurately detected by cubic spline interpolation method.

• Periodical: Advanced Materials Research (Volumes 960-961)
• Pages: 704-709
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.960-961.704
• Online since: June 2014
• Authors: Xiu Fang Jia, Hai Qing An*, Shao Guang Zhang
• Keywords: Cubic Spline Interpolation, Envelope Tracking, Power Quality, Voltage Flicker

References

[1] Dong Weijie，Bai Xiaomin，Zhu Ninghui，et al．Discussion on the power quality under Grid-connection of intermittent power sources[J]．Power System Technology，2013，37(5)：1265-1271 (in Chinese).

DOI: 10.1109/isgt-asia.2012.6303343

[2] A. Elnady，Yan-Fei Liu．A practical solution for the current and voltage fluctuation in power systems[J]．IEEE Transactions on Power Deliever，2012，27(3)：1339-1349.

DOI: 10.1109/tpwrd.2012.2187077

[3] Ma Yongqiang，Zhou Lin，Wu Jian，et al．A new approach to measure voltage flicker caused by interharmonics[J]．Power System Technology．2010，34(5)：117-121 (in Chinese).

[4] Li Heming，Kang Wei，Yan Xiangwu，et al．Voltage flicker measurement based on Chirp-Z transform[J]．Transactions of China Electrotechnical Society，2009，24(3)：209-215 (in Chinese).

[5] Li Tianyun，Zhu Lei，Dang Guoying，et al．Application of total least squares-estimation on signal parameters via rotational invariarce technique in extraction of voltage flicker parameters[J] ．Power System Technology，2009，33(13)：58-63 (in Chinese).

[6] Sun Shuqin．Voltage fluctuation and flickers[M]．Beijing：China Electric Power Press，1998，36-40(in Chinese).

[7] Xiao Xiangning．Analysis and control of power quality[M]．Beijing：China Electric Power Press，2010，112-115(in Chinese).

[8] Jia Xiufang，Chen Qing，Zhao Chengyong，et al．Comparison of the flicker detection methods[J]．High Voltage Engineering，2009，35(9)：2126-2132 (in Chinese).

[9] Jia Xiufang，Zhao Chengyong，Xu Guoyi，et al．Error analyzing of IEC flickermeter and its improving Design[J]．Transactions of China Electrotechnical Society，2006，21(11)：121-126．(in Chinese).

[10] Yang Hushan．The application and realization in actual problem of cubic spline interpolation [J] ．Journal of Xinzhou Teachers University，2008，24(2)：47-49．(in Chinese).

[11] Jia Xiufang，Chen Qing．Teager energy operator for tracking the envelope pf voltage flicker produced by integrated wind power[J] ．Acta Energiac Solaris Sinica，2010，31(7)：885-890(in Chinese).
