Study on Influence of Rock Strength on Anchorage Performance of Resin Anchored Bolts

Abstract:

Based on the introduction of the researches on the influence of the surrounding rock strength on the anchorage performance of resin anchored bolts at home and abroad, the numerical simulation was adopted to analyse anchorage system of single bolt support small-scale by using the finite difference program FLAC3D. The results showed that the stress distributions in resin capsules and surrounding rocks were different with the different strengths of surrounding rocks. The stresses in the surrounding rocks gradually decreased with the reduction of rock strength, but the plastic zone gradually expanded. On the basis, such technological approaches were brought forward to ensure support effect in the soft rock roadways by improving the materials and formulations of the resin capsules and increasing the support density and the anchorage length appropriately.

• Periodical: Advanced Materials Research (Volumes 962-965)
• Pages: 968-972
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.962-965.968
• Online since: June 2014
• Authors: Bin Hu*
• Keywords: Anchorage Performance, Resin Capsule, Rock Bolt, Surrounding Rock

References

[1] Zhongyuan Zheng, Naijiong Huang: Resin anchor bolts and capsules. Beijing：China Coal Industry Publishing House, 1992. (In Chinese).

[2] Shiliang Lu, Lei Tang, Xinan Yang: Anchorage force and anchorage technology of resin bolt. Beijing: China Coal Industry Publishing House, 2000. (In Chinese).

[3] Hongpu Kang, Jinhua Wang, Jian Lin: Case studies of rock bolting in coal mine roadways. Chinese Journal of Rock Mechanics and Engineering, vol. 29 (2010), p.649. (In Chinese).

[4] Hongpu Kang, Jinhua Wang: Rock bolting theory and complete technology for coal roadways. Beijing: China Coal Industry Publishing House, 2007. (In Chinese).

[5] Kılıc A, Yasar E, Atis C: Effect of bar shape on the pullout capability of fully-grouted rockbolts. Tunnelling and Underground Space Technology, vol. 18(2003), p.1.

DOI: 10.1016/s0886-7798(02)00077-9

[6] Bigby D: Coal Mine Roadway Support Handbook. Road Mechanics Technology Ltd for the Healthy and Safety Executive, (2004).

[7] Franklin JA, Wood field PR: Comparison of a polyester resin and a mechanical rock bolt anchor. Trans In st Min Metall (section -A: Mining Industry), 1971: A91~100.

[8] Karabin GJ, Debevec WL: Comparative evaluation of conventional and resin bolting systems. U.S. Department of the Interior, Mine Enforcement and Safety Administration, IR 1033, (1976).

DOI: 10.2172/5971975

[9] Cincilla WA: Determination of effective column lengths for resin grouted roof bolts. Peng SS: Proceedings of the Fifth Inter, national Conference on Ground Control in Mining, Morgantown, WV: West Virginia University, 1986, p.6~14.

[10] Qianli Cui: Study on Anchorage Performance and Influence Factors of Resin Bolt. Beijing：China Coal Research Institute, 2010. (In Chinese).

[11] Bin Hu: Study on Mechanical Properties of Resin Capsules for Full-length Pre-stressed Anchor Bolts. Beijing: China Coal Research Institute, 2011. (In Chinese).

[12] Bin Hu, Jian Lin, Pengfei Jiang: Influence of Ring Thickness of Anchored Agent on Anchored Quality of Resin Anchored Bolt. Coal mining Technology, vol. 16 (2011), p.20. (In Chinese).

[13] Wenwu Jiang, Guoyuan Xu, Changnian Ma: The application of fast lagrangian method to the numerical simulation of anchor bolt pull-out tests. China Railway Science, vol. 29 (2008), p.50. (In Chinese).

[14] Bin Hu, Hongpu Kang, Jian Lin, et al.: Study on influence of temperature on anchorage performance of resin anchored bolt. Journal of Mining and Safety Engineering, vol. 29 (2012), p.644. (In Chinese).
