Nonlinear Analysis of Underground Walls in Interaction with Subgrade

Abstract:

Effects of interaction between the structure and the subgrade represent an important factor that has to be considered within the structural design. Foundation structures as the bearing parts enter the structure-subgrade interaction processes considerably and the calculations have to be performed in detail. The paper presents modeling of the contact between the sheeting wall and the surrounding soil. Characteristics of particular contact elements used in ANSYS software follow. 2D and 3D models of the wall-soil contact have been created using various input data. In the conclusion, the obtained results have been presented and compared.

• Periodical: Advanced Materials Research (Volume 969)
• Pages: 276-279
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.969.276
• Online since: June 2014
• Authors: Ľubomír Prekop*
• Keywords: 3D Structural Model, Contact, Elastic Subgrade, Interaction, Sheeting Structure

References

[1] ANSYS Release 12. 1 Documentation. Swanson Analysis System IP, Inc., (2010).

[2] GEO 5 – User's guide. Fine, spol. s r. o., Bratislava, Slovakia 2007 (in Slovak).

[3] Hruštinec, Ľ.: Analysis of the interaction of shallow foundation with subsoil. Dissertation Thesis, Bratislava, 2002 (in Slovak).

[4] Prekop, Ľ.: Modeling of reinforced concrete structures using the ANSYS software. In.: 9th Ansys User's Meeting, Třešť, 2001 (in Slovak).

[5] STN 73 0037: Ground pressure acting upon the buidling structures (Slovak national standard).

[6] STN 73 1001: Foundation soil under the plane foundation (Slovak national standard).
