Structure and Oxidation Behavior of Gradient Zr/ZrN/Zr Diffusion Barrier on the Ni-Based Superalloy by Arc Ion Plating

Abstract:

Gradient Zr/ZrN/Zr layer was deposited as a diffusion barrier between the NiCrAlYSi The overlay coating and Ni-base superalloy DZ125 by arc ion plating(AIP). The microstructure and high-temperature oxidation behavior of the diffusion barrier were studied. The results show that the gradient diffusion barrier is homogeneous and compact, and has strong bond strength with the substrate. The diffusion barrier is composed of three layers, among which the inner and outer layers are rich in Zr, and the middle layer is rich in ZrN. The main phase structure of the diffusion barrier is ZrN(200). During high temperature oxidation at 1100°C, the Zr/ZrN/Zr/HY3 compound coating system presents excellent oxidation resistance.

• Periodical: Advanced Materials Research (Volumes 97-101)
• Pages: 1479-1483
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.97-101.1479
• Online since: March 2010
• Authors: Yan Cai, Chun Hu Tao, Feng Lu, Jian Ping Li
• Keywords: Arc Ion Plating (AIP), Gradient Diffusion Barrier, Vacuum Annealing (VA), Zr/ZrN/Zr

References

[1] J.P. Li, F. Lu,Y. Cai P.F. Zhang: Vacuum, Vol. 45(2008): 36(In Chinese).

[2] Y.M. Xiong,M. Sh. Li, Sh.L. Li: Materials Science and engineering of powder metallurgy, Vol. 12(2007): 36(In Chinese).

[3] H.Y. Lou, F.H. Wang: Vacuum, Vol. 43(1992): 757 (In Chinese).

[4] Knotek o; Loffler F, Beele W. Surface and Coatings Technology, Vol. 61(1993): 6-13.

[5] S.K. Jha Y.H. Sohn,S. Sastri,N. Gunda J.A. Haynes: Surface and Coatings Technology, Vol. 183(2004): 224-232.

DOI: 10.1016/j.surfcoat.2003.09.044

[6] R. Cremer , M. Witthaut, K. Reichert, M. Schierling, Surface and Coatings Technology, Vol. 108-109(1998): 48.

DOI: 10.1016/s0257-8972(98)00614-8

[7] Chun-MeiYang. Taiwan: National Sun Yat-sen university[D], (2000).

[8] Yan. Cai J.P. Li,P.F. Zhang, Feng. Lu: Chinese of aeronautics and astronautics 2007 Annual Conference . 2007, 9(In Chinese).

[9] G.H. Li,L.J. F,D.P. Xu. Welding, Vol. 29(2008): 09 (In Chinese).

[10] Metal handbook ninth edition volume 2: Properties and selection: Nonferrous alloys and pure metals. American society for metalspublishers(1994).

[11] H.X. Chen K.S. Zhou, Zh.P. J: Guandong non-ferrous materials, Vol. 22(2002): 63-66(In Chinese).

[12] Ch.J. Feng, L. Xin, M. SH. Li, Sh.L. Zhu, F.H. Wang: Chinese Society for Corrosion and protection, Vol. 28(2008): 5(In Chinese).
