Glass Fiber Permeability Using the VARTM Process

Abstract:

This study investigated a flow rate control system for the vacuum-assisted resin transfer molding (VARTM) process. Using Darcy’s equation, the permeability of multiaxial glass fiber composites is predicted and experimentally confirmed. The resin velocity vector is inversely proportional to the fiber mat length and resin viscosity, but proportional to the fiber mat permeability. In this study, the permeability of the preform and viscosity of the epoxy resin were measured using multiaxial glass fiber by VARTM. The permeability and time for impregnation differed according to the fiber direction in the VARTM process. The results indicated the need for further study of reinforcement fiber permeability in VARTM processing design.

You might also be interested in these eBooks

View Preview

Info:

Periodical:

Advanced Materials Research (Volumes 97-101)

Pages:

1772-1775

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.97-101.1772

Citation:

Cite this paper

Online since:

March 2010

Authors:

Yun Hae Kim, Dong Hun Yang, Chang Won Bae, Kyung Man Moon, Young Dae Jo, Sung Won Yoon, Hee Beom An

Keywords:

Filling Time, Glass Fiber, Permeability, VARTM

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] Xiaolan Song: Vacuum Assisted Resin Transfer Molding(VARTM) Model Development and Verification Doctor of Philosophy in Engineering Mechanics (2003), pp.1-4.

Google Scholar

[2] Jitendra S. Tate, Ajit D. Kelkar and John Rice: Feasibility Study of VARTM Manufacturing of Carbon Biaxial Braided Composite Using EPO49504 Epoxy Resin System Department of Mechanical Engineering North Carolina A & T State University.

Google Scholar

[3] Veronica M. A. Calado and Suresh G. Advani: Effective Average Permeability of Multi-layer Preforms in Resin Transfer Molding Composite Science and Technology Vol. 56 (1996), pp.519-531.

DOI: 10.1016/0266-3538(96)00037-1

Google Scholar

[4] I. S. Han, S. Y. Kim, S. K. Woo, K. S. Hong and D. W. Soe: Characteristics of Glass/Carbon Fiber Hybrid Composite Using by VARTM Journal of the Korean Ceramic Society Vol. 43 (2006), pp.607-612.

DOI: 10.4191/kcers.2006.43.10.607

Google Scholar
