The Adaptive Blade Design and Evaluation of Wind Turbine

Abstract:

This article explored the design method of the wind turbine blade being of flapping-twist adaptive performance and how to evaluate its feasibility and reliability according to the comprehensive factors. The results indicate that both spar cap and skin with off-axis carbon fiber can achieve the efficient flapping-twist coupling effect. Through overall investigation, the results show that the maximum fiber strains of tensile and compressive go up with increase of the off-axis angle, and the peak inter-laminar shear stress increase more rapidly. While, all of these evaluating indicators should be kept in the reference range for used materials. Moreover, when the off-axis angle increases, the peak Von Mises stress declines. In addition, the impact of natural frequencies on the blade design is proved to be insignificant. Finally, utilizing the medial axis laminates in the blade decoupled area is helpful to strengthen the blade fatigue resistivity.

• Periodical: Advanced Materials Research (Volumes 97-101)
• Pages: 2318-2323
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.97-101.2318
• Online since: March 2010
• Authors: Wang Yu Liu, Jia Xing Gong, Xi Feng Liu, Xin Zhang
• Keywords: Adaptivity, Flap-Twist Coupling, Medial Axis Laminate, Wind Turbine Blade

References

[1] Andrew T.; Richard G.: Compliant blades for wind turbines. in: IPENZ Transactions, Vol. 1/26 (1999), pp.7-12.

[2] Lobitz D.; Veers P.; Eisle G.: The use of twist-coupled blades to enhance the performance of horizontal axis wind turbines. in: SAND2001-1003(2001).

DOI: 10.2172/783086

[3] Ong C.; Tsai S.: Design manufacture and testing of a flapping-twist D-spar. in: SAND1999-1324 (1999), pp: 1-117.

[4] Griffin D.; Zuteck M.; Berry D.: Development of prototype carbon-fiberglass wind turbine blades: conventional and twist-coupled designs. in: AIAA-2004-0169, A Collection of the 2004 ASME Wind Energy Symposium(2004), pp.1-12.

DOI: 10.2514/6.2004-169

[5] Kyle K Wetzel. in: Journal of Solar Energy Engineering, Vol. 127(2005), pp.529-537.

[6] Liu wangyu; Gong jiaxing; Liu xifeng.: A kind of innovative design methodology of wind turbine blade based on natural structure. in: Information and Computing Science, 2009. ICIC '09. Second International Conference, Vol. 4(2009), pp.350-354.

DOI: 10.1109/icic.2009.399

[7] Ladean R.; Douglas S. John Mandell.: Analysis of a Composite Blade Design for AOC 10-50 Wind Turbine Using a Finite Element Model, in: SAND1999-1324(1999).

DOI: 10.2172/782707

[8] Dayton Groff.: Evaluation of Design Concepts for Adaptive Wind Turbine Blades. in: SAND 2002-2424(2002), pp.1-54.

[9] Hermann T.; Locke J.: Failure Analysis of Anisotropic Laminate Composites Utilizing Commercial FEA Software. in: AIAA-2005-0975 (2005), pp.370-381.

DOI: 10.2514/6.2005-975
