Effect of Process Routing on Machining Deformation for Multi-Frame Double Sided Monolithic Components

Abstract:

When machining aerospace monolithic components, a severe deformation can be observed due to the release and redistribution of the original residual stresses, together with the action of cutting loads and clamping force. In this paper, a finite element model predicting machining deformation was developed considering the above mentioned multi-factors coupling effects. Based on the model, the effect of process routing on machining deformation for multi-frame double sided monolithic components was studied. To validate the FE model, true frame components were machined and deformations were measured on a Coordinate Measuring Machine. The result revealed that the prediction model is credible. At last the paper puts forwards optimal process routing based on minimizing the machining deformation.

• Periodical: Advanced Materials Research (Volumes 97-101)
• Pages: 2894-2897
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.97-101.2894
• Online since: March 2010
• Authors: Zhi Tao Tang, Zhan Qiang Liu, Li Qiang Xu
• Keywords: Machining Deformation, Monolithic Component, Process Routing

References

[1] S. Ratchev, S. Liu, W. huang: Int. J. Mach. Tools Manuf vol. 44 (2004) , pp.1629-1641.

[2] H. Y. Dong, Y. L. Ke, Q. Wu and D. Xu: Acta Aeronautica ET Astronautica Sinica vol. 124 (2004), pp.382-384 (In Chinese).

[3] Keith A. Young: Machining-induced residual stress and distortion of thin parts. Ph. D dissertation. Washington University, USA (2005).

[4] Z. Y. Mei, Y. Q. Wang and Y. Q. Fan: Acta Aeronautica ET Astronautica Sinica vol. 26 (2005), pp.234-239 (In Chinese).

[5] K. Wu, N. He, W. H. Liao and W. Zhao: China Mechanical Engineering, vol. 15 (2004), pp.670-674 (In Chinese).

[6] Z. T. Tang, Z.Q. Liu, X. Ai: Adv. Mater. Res vol. 24-25 (2007), pp.355-360.
