Sticking Analysis of the Bistable Inductive Micro-Switch

Abstract:

Problems of the “false closure” and “instant closure” affect the antijamming capability and reliability of the micro-switch. Based on the sticking action, a new bistable micro-switch is put forward. A sine model is presented to describe the random distribution of the MEMS rough surface. Based on the sine rough model, the Casimir adhesion is simulated. The electric field force, which includes the edge effect, is discussed. Finally the threshold structure size is obtained, which can control the micro-switch to close stably and trigger automatically.

• Periodical: Advanced Materials Research (Volumes 97-101)
• Pages: 2876-2879
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.97-101.2876
• Online since: March 2010
• Authors: Wen Chao Tian, Huo Rong Ren, Liin Bin Wang, Huan Ling Liu
• Keywords: Adhesion, Casimir Force, Edge Effect, Inductive Micro-Switch

References

[1] Jian Zhao, Jianyuan Jia, iaoping He, Journal of Applied Mechanics, 75(7), 41020 (2008).

[2] Du Y., Chen L., McGruer N.E., Adams G.G., Etsion I., Journal of Colloid and Interface Science, 312 (2), 522 (2007).

[3] R. Esquivel-Sirvent, Europhysics letters, 84, 48002 (2008).

[4] Andojo Ongkodjojo, Francis E. H. Tay, Journal of Physics: Conference Series, 34, 1044 (2006).

[5] C. Hertlein, L. Helden, A. Gambass, S. Dietrich, C. Bechinger, Nature, 451(10), 172 (2008).

[6] Philip Ball, Feel the force, Nature, 447(14), 772 (2007).

[7] H. B. Chan, V. Aksyuk, R. N. Kleiman, D. J. Bishop, Federica Capasso, Science, 291(9), 1941 (2001).
