Research on Machining Simulation System for Optical Free-Form Surfaces

Abstract:

This paper presents a new simulation system for ultra-precision diamond turning of optical free-form surfaces based on fast tool servo (FTS). The functions including evaluation and analysis of optical free-form surfaces manufacturing errors, optimization for tool path, etc, are proposed. The simulation modules and functional structure of the system are designed in accordance with the functions. The errors in the process of machining can be found in advance through the simulation. Then the NC code will be modified timely. The proposed method can be used to improve product quality, shorten the development cycle, reduce costs and optimize machining process.

• Periodical: Advanced Materials Research (Volumes 97-101)
• Pages: 3020-3023
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.97-101.3020
• Online since: March 2010
• Authors: Yong Hu, Ming Xu Xu, Jun Zhang, Bo Mao, Xiao Qin Zhou
• Keywords: Dynamic Simulation, Fast Tool Servo (FTS), NC Code, Optical Freeform Surface
