Structural Optimization of Non-Contact Vortex Negative Pressure Carrier

Abstract:

Simulation models based on the different structural levitation vortexes were built, the analysis on the flow characteristics of pressure distribution and bearing capacity was conducted by using the RNG κ-ε turbulent model and non-uniform meshing in variable working conditions. At last, the influence factors and variation rules of vortex adsorption negative pressure effect were obtained. The theory and the experiment results indicate that the vortex carrier with symmetrical tangential air supply has the optimal stability, but the optimal negative pressure effect and the great lifting force are obtained by the vortex carrier with tangential single air supply.

• Periodical: Advanced Materials Research (Volumes 97-101)
• Pages: 3219-3224
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.97-101.3219
• Online since: March 2010
• Authors: Wen Qi Ma, Li Fang Xu, He Chun Yu
• Keywords: Lifting Force, Negative Pressure, Non-Contact Carrier, Vortex Levitation

References

[1] Liantong Men, Shufan Bai, in: Logistics Technology, Doi: CNKI: SUN: WLJS: O2006-05-009 (2006). In Chinese.

[2] Xin Li, Kenji Kawashima, Toshiharu Kagawa, Analysis of vortex levitation, Experimental Thermal and Fluid Science, 32(2008), 1448-1454.

DOI: 10.1016/j.expthermflusci.2008.03.010

[3] S. Davis, J.O. Gray, D.G. Caldwell, An end effector based on the Bernoulli principle for handling sliced fruit and vegetables, Robotics and Computer-Integrated Manufacturing, 24 (2) (2008), 249-257.

DOI: 10.1016/j.rcim.2006.11.002

[4] Er'zhuang Yang，Baosen Sha，Shoude Chen, in：Hydraulics Pneumatics & Seals. 100823. In Chinese.

[5] Fujun Wang, Analysis of computational fluid dynamics ---Principle and Application of CFD software, Beijing: Tsinghua University Press (2004). In Chinese.
