A Structural Topological Optimization Method Based on Varying Displacement Limits and Design Space Adjustments

Abstract:

In the proposed topology optimization method, the whole optimization process is divided into two phases. Firstly，an optimization model dealing with varying displacement limits and design space adjustment approaches， after the combination of structural discrete topology variable condition and the original objective， are built. Secondly，incorporating smooth optimization algorithm，a procedure is proposed to solve the optimization problem of the first optimization adjustment phase. This design space adjustment capability is automatic when the design domain needs expansion or reduction, and it will not affect the property of mathematical programming method convergences. The structural topology approaches to the vicinity of the optimum topology when the first optimization adjustment phase ends. Then, a heuristic algorithm is given to make the topology of the design structure be of solid/empty property and the optimum topology is obtained during the second optimization adjustment phase. The simulation shows that the topologies obtained by the proposed method are of very good 0-1 distribution property, the proposed method is robust and efficient.

• Periodical: Advanced Materials Research (Volumes 97-101)
• Pages: 3609-3616
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.97-101.3609
• Online since: March 2010
• Authors: Jian Hua Rong, Wei Xiang Li, Bing Feng
• Keywords: Continuum Structure, Design Space Adjustment, Displacement-Constraint, Rational Approximation Material Model, Topological Optimisation, Varying Displacement Limits

References

[1] I. Y . Kim, B.M. Kwak： Design space optimization using a numerical design continuation method. Int. J. Numer. Methods Eng. Vol. 53（2002），p. (1979).

DOI: 10.1002/nme.369

[2] I.G. Jang， B.M. Kwak： Evolutionary topology optimization using design space adjustment based on fixed grid. Int. J. Numer. Methods Eng. Vol. 66(2006)，p.1817.

DOI: 10.1002/nme.1607

[3] I.G. Jang， B.M. Kwak： Design space optimization using design space adjustment and refinement. Structural and Multidisciplinary Optimization. Vol. 35（2008），p.41.

DOI: 10.1007/s00158-007-0112-8

[4] Y.K. Sui, D.Q. Yang： A new method for structural topological optimization based on the concept of independent continuous variables and smooth model. Acta Mechanica Sinica. Vol. 18（1998 ） ， p.179.

DOI: 10.1007/bf02487752

[5] Y.K. Sui, X.R. Peng：The ICM method with objective function transformed by variable discrete condition for continuum structure. Acta Mechanica Sinica . Vol. 22（2006），p.68.

DOI: 10.1007/s10409-005-0088-9

[6] K. Svanberg, M. Werme： On the validity of using small positive lower bounds on design variables in discrete topology optimization. Structural and Multidisciplinary Optimization. DOI 10. 1007/s00158-008-0248-1（2009）.

DOI: 10.1007/s00158-008-0248-1

[7] M. Stolpe ， K. Svanberg：An alternative interpolation scheme for minimum compliance topology optimization . Structural and Multidisciplinary Optimization，Vol. 22（2001），p.116.

DOI: 10.1007/s001580100129

[8] J.H. Rong, X. J. Xing, G. Deng：A structural topological optimization method with variable displacement limits, Chinese Journal of Theoretical and Applied Mechanics. Vol. 41 (2009), p.431 (in Chinese).
