The Research of Digital Soft Switching Arc-Welding Inverter

Abstract:

This paper discusses the characteristics of welding power supply, and then gives the design ideas of digital welding power. A full-bridge configuration which cooperates with high frequency transformer and rectifier circuit is used to be main circuit, and IGBT is the primary switch component. The leading leg achieves Zero Voltage Switching, and the lagging leg is Zero Current Switching by the combination of soft switching and inverter technology. We take UC3879 as the core of PWM controlling to carry out soft switching and TMS320LF2407A as the core of all controlling system. The control strategy adopts fuzzy-PID control.

• Periodical: Advanced Materials Research (Volumes 97-101)
• Pages: 4084-4087
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.97-101.4084
• Online since: March 2010
• Authors: Gui Xi Jia, Yang Zhang, You Wen Xiao, Yuan Su
• Keywords: Digital Signal Processor (DSP), Soft Switching, Welding Inverter

References

[1] Zhilin Jiang and Shisheng Huang, in: volume 5 of ELECTRIC WELDING MACHING, (1996), pp.6-10. (In Chinese).

[2] Guixi Jia, Jintao Liu and Fang Zhang, in: volume 25 of Transactions of the China Welding Institution, 6. (2004) (In Chinese).

[3] Xinbo Ruan and Yangguang Yan, in: volume 48 and NO. 4 of IEEE TRANSACTIONS ON INDUSTRIAL ELECTRONICS, (2001), p.777~785.

[4] Zengfu Wang, Chang Li and Yongming Wei: Principle and Application of Soft Switching Power (Publishing House of Electronics Industry, Beijing, 2006), pp.192-260. (In Chinese).

[5] Ushio M, Yamamoto H, in: volume 34 of Welding in the wording, (1994), p.185~191.

[6] Liguo Yu, Xiumei Wang, Jinxing Du, Yanmang Su and Changli Ning, in: volume 34 of Welding Technology, 4. (2005), p.4~6. (In Chinese) Vce.
