A Three-Phase Constitutive Model for TiNiNb Shape Memory Alloys

Abstract:

A three-phase constitutive model for TiNiNb shape memory alloys (SMAs) is proposed based on the fact that TiNiNb SMAs are dynamically composed of austenite, martensite and -Nb phases. In the considered ranges of stress and temperature, the behaviors of austenite, martensite and -Nb phases are assumed to be elastoplastic, and the behavior of an SMA is regarded as the dynamic combination of the individual behavior of each phase. Then a macroscopic constitutive description for TiNiNb SMAs is obtained by the conventional theory of plasticity, the theory of mixture, the theory of inclusion, and the description of phase transition by Tanaka. The method for determination of the material parameters is given. This constitutive model can describe the main characteristics of SMAs, such as ferrcelasticity, pseudoelasticity and shape memory effect.

• Periodical: Advanced Materials Research (Volumes 97-101)
• Pages: 660-666
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.97-101.660
• Online since: March 2010
• Authors: Jun Wang, Zhi Ming Hao, Ping An Shi, Shao Rong Yu, Wei Fen Li
• Keywords: Constitutive Model, Shape Memory Alloy Actuator, Theory of Plasticity, Three-Phase Material

References

[1] Achenbach M, Atanackovic T, Muller I. A model for memory alloys in plane strains. Int J Solids Struct, 1986, 22(2): 171～(1932).

[2] Zou Jing, Zhong Weifang. The multi-dimensional constitutive relations of shape memory alloys. ACTA Mechanica Solida Sinica, 1999, 20(2): 172～1763.

[3] Tanaka K, Kobayashi S, Sato Y. Thermomechanics of transformation pseudoelasticity and shape memory effect in alloys. Int J Plasticity, 1986, 2: 59～724.

DOI: 10.1016/0749-6419(86)90016-1

[4] Liang C and Rogers C A. One dimensional thermomechanical constitutive relations for shape memory materials. J Int Mater Syst and Struct, 1990, 1: 207～2345.

DOI: 10.2514/6.1990-1027

[5] Boyd J G. Thermomechanical response of shape memory composites. J Intell Mater Syst and Struct, 1994, 5: 333～3466.

[6] Patoor E, Eberhardt A, Berveiller M. Thermomechanical behavior of shape memory alloys. Arch Mech, 1988, 40: 775～7947.

[7] Sun Q P, Hwang K C. Micromechanics modeling for the constitutive behavior of polycrystalline shape memory alloys. J Mech Phys Solids, 1993, 41(1): 1～338.

[8] Yang Qingsheng. Thermomechanical properties of smart composites. ACTA Mechanica Solida Sinica, 1996, 17(4): 339～3429.

[9] Peng X, Yang Y, Huang S. A comprehensive description for shape memory alloys with a two phase constitutive model . Int J Solid Struct, 2001, 38: 6925～6940.

DOI: 10.1016/s0020-7683(00)00402-9

[10] Li Haitao, Peng Xianghe, Huang Shanglian. Aconventional plasticity based two-phase constitutive model for shape memory alloys. 2004, 25(1): 58～62.

[11] L C Zhao. Materials Science Forum, 2000, 327~328: 23-30.

[12] C S Zhang. Mater Chem Phys, 1991, 28: 43.
