The Simulation Analysis of the High Speed Switch Valve Control the Cartridge Valve Based on AMEsim

Abstract:

To establish the mathematical model of the system of high speed switch valve control the cartridge valve based on analyzing the working principle of the system,and then to analyze the impact of selecting different input signal of high speed solenoid valve and different duty cycle of PWM pulse width modulated signal through simulation software AMSEsim. The results obtained in the high-frequency performance is not very satisfactory, but in the low signal and moderate duty cycle, high-speed switch valve can be good linear control of the cartridge valve.
