The Structure Analysis of the Amphibious Robot’s Propeller Based on Fluid-Solid Coupling

Abstract:

This paper based on ANSYS Workbench software, the method of fluid-structure interaction analysis about propeller of wheel-propeller integrated amphibious robot was presented. The CFX fluid calculation results were taken as loads exerted on the propeller and the corresponding stress at nodes between fluid and structure were exerted on the FE model of the structure. Finally, the calculation method of one-way coupling and further structure analysis of the propeller was completed. At last, the calculation results indicate that the propeller of the amphibious robot can meet the engineering requirements. The results provide favorable basis for the optimal design of propeller.

• Periodical: Advanced Materials Research (Volumes 971-973)
• Pages: 836-839
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.971-973.836
• Online since: June 2014
• Authors: Zi Yue Wu*, Jie Qi, Kang Gao
• Keywords: Fluid-Structure Interaction Analysis, One-Way Coupling, Propeller, Structure

References

[1] Y. G Tang, A. Q Zhang, J. C Yu and X. Q Zhang. Multi-obhective Optimization Design for the Wheel-Propeller-Leg Driving Mechanism of an Amphibious Robot. ROBOT, Vol. 31(2009).

DOI: 10.1109/icic.2009.327

[2] X. G Song, H Zhang and L Cai. Fluid–structure interaction analysis of ANASYS and Engineering Examples, China WaterPower Press, (2012), in press.

[3] F. J Wang. The analysis of Computational Fluid Dynamics-CFD Software principle and application, Tsinghua University Press, (2004), in press.

[4] L. H Xie, X. Y Zhang and J. M Zhang. Fluid analysis and Simulation of ANSYS CFX, Electronic Industry Press, (2012), in press.

[5] Y. Y Xie, Z. H Duan and L Sun. Overview of Numerical Method of Fluid-Structure Interaction System and the Applied Software, Guangzhou Chemical Industry, Vol. 29(2011), pp.35-37.

[6] D. Soares Jr., W.J. Mansur. Dynamic analysis of fluid–soil–structure interaction problems by the boundary element method, Journal of Computational Physics, Vol. 219(2006), pp.45-47.

DOI: 10.1016/j.jcp.2006.04.006
