Optimization of Control and Combustion on a 330MW Face-Fired Boiler

Abstract:

A pair of contradictory problems of unstable combustion at low load and serious slagging near the burners, appear on a 330MW boiler made by Babocock. By diagnosis from aspects of the distributed control system (DCS) control logics and the boiler operation modes, it is found that the root cause is the coarse controlling of primary air (PA) flow which is caused by improper measure or calculation logical blocks of DCS. These improper DCS control logics are corrected. The PA flow rates are calibrated by tests in order to get precise coefficients for the new logic. The combustion mode, the control curves of the primary air pressure and the secondary air pressure are optimally adjusted at last. As a result, the boiler efficiency increases by 0.75%, the power consumption rate decreases by 0.2%, the NOx emission concentration reduce to half.

• Periodical: Advanced Materials Research (Volume 977)
• Pages: 315-320
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.977.315
• Online since: June 2014
• Authors: Qing Feng Zhang*
• Keywords: Boiler, Combustion, Face-Fired, Optimization

References

[1] ZHOU Qiang-tai. Boiler principle (Version 2)[M]. Beijing: China Electric Power Press, (2010).

[2] CEN Ke-fa. Test methods and measurement techniques of boiler combustion [M]. Beijing: Hydraulie Power and Electric Power Press, (1987).

[3] WU Dong-yin, SHENG Hong-zhi, WEI Xiao-li, et al. The optimized experiments of milling system for coal-fired boiler[J]. Proceedings of the CSEE, 2004, 24(12): 100-103.

[4] XU Xian-bin, LENG Jie, PAN Jing, et al. Analysis for the misunderstanding in medium-speed pulverizing system operation [J]. Electric Power, 2005, 38(7): 46-49.

[5] LI Yong-hua, CHEN Hong-wei, MENG Fan-jun. An experimental study on optimal combustion control for a boiler of 300MW [J]. Proceedings of the CSEE, 2004, 24(1): 216-220.

[6] ZHAO Zhen-ning. Compressive Optimation of primary air parameters of medium-speed pulverizing system [J]. Proceedings of the CSEE, 2010, 30(Supplement): 124-130.

[7] ZHAO Zhen-ning, LU Xiao, AN Lian-suo, et al. Properies analysis and Optimation of primary air flow in power station[J]. Power System Engineering, 2009, 25(5): 23-26.

[8] ZHAO Zhen-ning, ZHAO Zhen-zhou, ZHANG Qing-feng, et al. Rebuilding of combustion control system for direct-fired boilers with coal feeder of non-weighting type[J]. Journal of Chinese Society of Power Engineering, 2012, 30(23): 19-23.

[9] ZHOU Jun-hu, ZHAO Chen-jie, XU Jian-hua, et al. Application of air-staged and low NOx emission combustion technology in plant power[J]. Proceedings of the CSEE, 2010, 30(23): 19-23.

[10] Calculating method of economical and technical index for thermal power plant DL/T 904-2004 [S]．2004.
