Research on Car-Rail Coupling Dynamics of Ascending Hatchway of Elevator Safety Device Test Tower

Abstract:

The hatchway structure and operating mode were described according to the key technology of elevator safety device test tower. According to mounting structure of the ascending hatchway, the constraints of car-rail were proposed. According to constrains, the car-rail coupling dynamics models of moving and rotating were proposed at x-axis, y-axis and z-axis, and the vibration models were simplified to moving and rotating at z-axis. Based on simplified model, the dynamic characteristics of car were simulated when safety gear broken.

• Periodical: Advanced Materials Research (Volume 978)
• Pages: 135-138
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.978.135
• Online since: June 2014
• Authors: Qing Song Jiang*, Jian Ping Ye, Jia Fan Zhang
• Keywords: Car-Rail, Coupling Dynamics, Elevator Safety Device, Test Tower

References

[1] Saligrama. R. Venkatesh, Young Man Cho, Jongwon Kim，Robust control of vertical motions in ultra-high rise elevators，Control Engineering Practice 10 (2002) , p.121–132.

DOI: 10.1016/s0967-0661(01)00111-3

[2] W.D. Zhua, L.J. Teppo，Design and analysis of a scaled model of a high-rise, high-speed elevator，Journal of Sound and Vibration 264 (2003), p.707–731.

DOI: 10.1016/s0022-460x(02)01218-x

[3] Jozef Filas, Martin MudroĖ，The dynamic equation of motion of driving mechanism of a freight elevator，Procedia Engineering 48 ( 2012 ) , p.149–152.

DOI: 10.1016/j.proeng.2012.09.498

[4] Yoshiaki YAMAZAKI, Masao TOMISAWA, Kouji OKADA, Vibration Control of Super-High-Speed Elevators, JSME International Journal, series C, Vol. 40, No. 1 (1997) , pp.74-81.

DOI: 10.1299/jsmec1993.40.74

[5] Jovan Vladic, Radomir Djokic, Milan Kljajin, Mirko Karakasic, Modelling and Simulations of Elevator Dynamic Behaviour，Technical Gazette, 18, 3(2011), pp.423-434.

[6] BAO Ji-hu, ZHANG Peng, Modeling and control of longitudinal vibration on flexible hoisting systems with time-varying length Procedia Engineering 15 (2011), p.4521 – 4526.

DOI: 10.1016/j.proeng.2011.08.849

[7] Yuan Xiao, Jianping Ye，Research and Design on Mechanical System of Elevator Tower for Safety Devices, Applied Mechanics and Materials Vol. 421 (2013).

DOI: 10.4028/www.scientific.net/amm.421.72

[8] Xabier Arrasate，Stefan Kaczmarczyk, The modelling, simulation and experimental testing of the dynamic responses of an elevator system, Mechanical Systems and Signal Processing 42 (2014), p.258–282.

DOI: 10.1016/j.ymssp.2013.05.021

[9] R. -F. FUNG,J. -H. LIN, C. -M, YAO, Vibration Analysis And Suppression Control of an Elevator String Actuated by a PM Synchronous Servo Motor, Journal of Sound and Vibration (1997) 206(3) , p.399–423.

DOI: 10.1006/jsvi.1997.1102
