Effects of YMnO₃ Addition on Phase Structure, Microstructure and Electrical Properties of (Na_0.515K_0.485)_0.9₄Li_0.0₆(Nb_0.8Ta_0.2)O₃ Lead-Free Ceramics

Abstract:

The (1-x)[(Na_0.515K_0.485)_0.9₄Li_0.0₆(Nb_0.8Ta_0.2)O₃]-xYMnO₃ (x = 0, 0.005, 0.01, 0.015 and 0.02) lead-free ceramics were synthesized by solid-state reaction sintering method. It was found that the addition of YMnO₃ affected on the grain size, phase structure and electrical properties of (Na_0.515K_0.485)_0.94Li_0.06(Nb_0.8Ta_0.2)O₃ ceramics. The grain size decreased with increasing YMnO₃ content (x ≥ 0.01) and led to poor densification. The ceramic doped with 0.5 mol% YMnO₃ showed good electrical properties such as d₃₃ = 195 pC/N, k_p = 43.9 %, T_c = 292 °C, T_O₋_T = 35 °C, ε_r = 820 and rather low dielectric dissipation factor = 2.1%. This indicates that 0.5 mol% YMnO₃ -doped (Na_0.515K_0.485)_0.94Li_0.06(Nb_0.8Ta_0.2)O₃ piezoceramic is an alternative lead-free piezoelectric material for the development of piezoelectric devices working at high temperature.

You might also be interested in these eBooks

View Preview

Info:

Periodical:

Advanced Materials Research (Volume 979)

Pages:

167-170

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.979.167

Citation:

Cite this paper

Online since:

June 2014

Authors:

Pornsuda Bomlai*

Keywords:

Dielectric, Doping, Lead-Free Materials, Piezoelectric

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] Y. Saito, H. Takao, T. Tani, T. Nonoyama, K. Takatori, T. Homma, T. Nagaya, M. Nakamura, Lead-free piezoceramics, Nature. 432 (2004) 84-87.

DOI: 10.1038/nature03028

Google Scholar

[2] H. Birol, D. Damjanovic, N. Setter, Preparation and characterization of (K0. 5Na0. 5)NbO3 ceramics, J. Eur. Ceram. Soc. 26 (2006) 861-866.

DOI: 10.1016/j.jeurceramsoc.2004.11.022

Google Scholar

[3] Y. Guo, K.I. Kakimoto, H. Ohsato, Phase transitional behavior and piezoelectric properties (Na0. 5 K0. 5)NbO3 – LiNbO3 ceramics, Appl. Phys. Lett. 85 (2004) 4121-4123.

DOI: 10.1063/1.1813636

Google Scholar

[4] ‏ Y. Saito, H. Takao, High performance lead-free piezoelectric ceramics in the (K, Na)NbO3– LiTaO3 solid solution system, Ferroelectrics. 338 (2006) 17-32.

DOI: 10.1080/00150190600732512

Google Scholar

[5] G. Teowee, K.C. Mccarthy, F.S. Mccarthy, T.J. Bukowski, D.G. Davis, D.R. Uhlmann, Dielectric and ferroelectric properties of sol-gel derived YMnO3 films, J. Sol-Gel Sci. Technol. 13 (1998) 899-902.

DOI: 10.1023/a:1008623323530

Google Scholar

[6] Z. Yang, X. Chao, C. Kang, R. Zhang, Low temperature sintering and properties of piezoelectric PZT–PFW–PMN ceramics with YMnO3 addition, Mater. Res. Bull. 43 (2008) 38-44.

DOI: 10.1016/j.materresbull.2007.02.020

Google Scholar

[7] P. Bomlai, P. Sinsap, S. Muensit, S.J. Milne, Effect of MnO on the phase development, microstructures, and dielectric properties of 0. 95Na0. 5K0. 5NbO3 – 0. 05LiTaO3 ceramics, J. Am. Ceram. Soc. 91 (2008) 624-627.

DOI: 10.1111/j.1551-2916.2007.02130.x

Google Scholar

[8] D.Y. Jeong, J. Ryu, D.S. Park, Effect of YMnO3 on the high-power and high-temperature piezoelectric characteristics of Pb(Zr0. 52Ti0. 48)O3 ceramics, Mater. Sci. Eng. B. 163 (2009) 88-92.

DOI: 10.1016/j.mseb.2009.05.012

Google Scholar

[9] P. Zheng, J.L. Zhang, Y.Q. Tan, C.L. Wang, Grain-size eﬀects on dielectric and piezoelectric properties of poled BaTiO3 ceramics, Acta Mater. 60 (2012) 5022-5030.

DOI: 10.1016/j.actamat.2012.06.015

Google Scholar

[10] B.R. Li, X.H. Wang, L.T. Li, H. Zhou, X.T. Liu, X.Q. Han, Y.C. Zhang, X.W. Qi and X.Y. Deng, Dielectric properties of fine-grained BaTiO3 prepared by spark-plasma-sintering, Mater. chem. Phys. 83 (2004) 23-28.

DOI: 10.1016/j.matchemphys.2003.08.009

Google Scholar
