Analysis of Electric Field Homogenization of Converter Transformer Barrier System Based on Nano Modification of Pressboard

Abstract:

In order to solve the problem of non-uniform electric field distribution in converter transformer barrier system caused by conductivity difference between the transformer oil and pressboard, the SiC(silicon carbide) modified pressboard was developed by nano doping method. The conductivity of modified pressboard was measured. The measuring results show that the conductivity of modified pressboard increases exponentially with the increase of nano SiC doping ratio. The electric field strength has obvious influence on conductivity at high nano doping ratio, which shows great nonlinear characteristic. Based on the nonlinear conductivity characteristic of modified pressboard, the homogenizing effect of the nano modified pressboard on electric field distribution was verified by simulation. The simulation results show that the electric field distribution under DC and polarity reversal voltage in barrier system can be well homogenized by using the nonlinear characteristic of nano modified pressboard.

• Periodical: Advanced Materials Research (Volume 981)
• Pages: 940-945
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.981.940
• Online since: July 2014
• Authors: Qing Guo Chen*, He Qian Liu, Xiang Li Zhuge, Ming He Chi, Xin Lao Wei
• Keywords: Barrier System, Converter Transformer, Electrical Field Distribution, Nano-Modification, Nonlinear

References

[1] Yan Li, Xiaohui Li, Cong Tang and Dongxue Li: High Voltage Engineering. Vol. 38, No. 11 (2012), pp.2797-2804(In Chinese).

[2] J. Robertson, B. R. Varlow: IEEE Transactions on Dielectrics and Electrical Insulation. Vol. 12, No. 4 (2005), pp.779-790.

DOI: 10.1109/tdei.2005.1511103

[3] Wenmin Guo: Research on non-linear conductive characteristics and mechanisms of polyethylene composites filled with inorganic filler, (In Chinese). Harbin: Harbin University of Science and Technology. pp.27-34 (2010).

[4] Baozhong Han, Wenmin Guo and Zhonghua Li: Functional Materials. Vol. 9, No. 39 (2008), pp.1490-1493 (In Chinese).

[5] Qingguo Chen, Jie Zhang, Yuan Gao and Xinlao Wei: High Voltage Engineering. Vol. 34, No. 3 (2008), pp.484-488 (In Chinese).

[6] Yuan Gao, Qingguo Chen, Guangjun Li, Xinlao Wei and Yonghong Wang: Analysis of electrical field on valve side winding of converter transformer,. Proceedings of the 9th International Conference on Properties and Applications of Dielectric Materials. pp.85-88 (2009).

DOI: 10.1109/icpadm.2009.5252500
