Simulation Analysis of Kinematics and Dynamics of 3-TPS Hybrid Robot

Abstract:

The paper aims at the questions of electromotor selection and mechanism design, which is effectively solved by the virtual prototype technology. Firstly, the three-dimensional model of hybrid machine tool is built by using SolidWorks software. Secondly, the assembled model is channeled into ADAMS/View, and then formed the virtual prototype simulation model with mute-body dynamics. Velocity and driving force curve of each driving shaft is got by analyzing the kinematics and dynamics of the hybrid machine tool. Maximum velocity and maximum driving force each driving shaft can find out by the method of space search. Therefore, the kinematics and dynamics properties of 3-TPS hybrid machine tool is obtained, which provide proof for machine electromotor selection, framework design and control system design. Key words: Hybrid robot; Kinematics; Dynamics; ADAMS; Simulation

• Periodical: Advanced Materials Research (Volume 983)
• Pages: 379-382
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.983.379
• Online since: June 2014
• Authors: Jia Shun Shi, Shuang Wang, Li Da Zhu*, Wan Shan Wang, Tian Biao Yu
• Keywords: Adam, Dynamic, Hybrid Robot, Kinematics, Simulation

References

[1] Lee M K, Park K W. Kinematic and dynamic analysis of a double parallel manipulator for enlarging workspace and avoiding singularities [J]. I EEE Transactions on Robotics and Automation, 1999, 15: 1025 - 1033.

DOI: 10.1109/70.817667

[2] Huang T, Whitehouse D J, Wang J S. The local dexterity optimal architecture and design criteria of parallel machine tools[J]. Annals of the CIRP, 1998, 47 (1): 347 - 351.

DOI: 10.1016/s0007-8506(07)62848-0

[3] L. Romadhane. Design and analysis of a hybrid serial-parallel manipulator[J] , Mechanism and Machine Theory, 34(1999)：1037-1055.

DOI: 10.1016/s0094-114x(98)00079-2

[4] Cai G Q , Wang Q M , Hu M , et al. Study on the kinematics and dynamics of a 3-DOF parallel machine tool [J]. Journal of Materials Processing Technology, 2001, 111(1-3): 269 - 272.

DOI: 10.1016/s0924-0136(01)00532-5

[5] Rasim S, Alizade I. Forward and reverse displacement analysis of a 62DOF in2parallel manipulators [J]. International Journal of Tools & Manufacture, 1997, 39(2): 321 - 342.

[6] Kong X W, Gosselin C M. Uncertainty Singularity Analysis of Parallel Manipulators Based on the Instability Analysis of Structures[J], The International Journal of Robotics Research, 2001, 20(11): 847-856.

DOI: 10.1177/02783640122068146

[7] Huang Z, Chen L H, Li Y W. The Singularity Principle and Property of Stewart Parallel Manipulator [J], Journal of Robotic Systems, 2003, 20(4): 163-176.

DOI: 10.1002/rob.10078
