Implementation of Single Phase Locked Loop Based on FPGA and its Application in SVC

Abstract:

Whereas three-phase phase locked loop could not get accurate phase position under three-phase unbalanced condition of the power grid, the design of single phase locked loop is implemented in the principle of single phase locked loop, based on FPGA technology. the paper explains design difficulties of single phase locked loop in detail, puts forward adaptive sampling scheme using single phase locked loop under variable frequency, increases accuracy of SVC sampling system. And tests response speed of phase locked loop via Real Time Digital Simulator for Power Systems (RTDS), through final verification in Fushun Lishizhai SVC Project, the design could meet system requirement for voltage phase accuracy.

• Periodical: Advanced Materials Research (Volumes 986-987)
• Pages: 1826-1832
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.986-987.1826
• Online since: July 2014
• Authors: Yu Jie Pei*, Yun Shan Zhang, Jian Guo Xu, Jing Long Mu, Lei Zhang, Pin Dong, Bo Cong, Shu Han Wang
• Keywords: Adaptive Sampling, FPGA, RTDs, Single Phase Locked Loop, Three-Phase Unbalance

References

[1] Sang-Joon Lee, Jun-Koo Kang, Seung-Ki Sul. A New Phase Detecting Method for Power Conversion Systems Consid-ering Distorted Conditions in Power System[A]. Industry Applications Conference, Conf. Record of the IEEE'99, 1999: 2167-2172.

DOI: 10.1109/ias.1999.798754

[2] Shu Zeliang, Guo Yuhua, Tang Jian. Implementation of Three-Phase Phase-Locked Loop Based on FPGA [J]. Power and electronic technology, 2005, 39(6): 126-128.

[3] Wu Bo, Guo Yuhua, Wen Yuliang. the Improvement of Single-Phase Power Phase-Locked Loop and Its Implementation Based on FPGA [J]. Power and electronic technology, 2008, 42.

[4] Hong-Seok Song, KWanghee Nam, Peter Mutschler. Very Fast Phase Angle Estimation Algorithm for a Single –Phase System Having Sudden Phase Angle Jumps [A]. IEEE Industry Applications Conference, Con. Record of the 2002 37th IAS Annual Meeting, 2002: 925-937.

DOI: 10.1109/ias.2002.1042669

[5] Petar mdjuric, Miroslav mbegovic, Milos doroslovaeki. Instantaneous Phase Tracking in powernetworks by Demodulation [J]. IEEE Trans. On Instrumentation and Measurement, 1992: 963-967.
