Computation and Analysis of Static and Dynamic Radial Stability of Power Transformer Inner Winding

Abstract:

In this paper, the size of winding electromagnetic force after short circuit has been acquired through leakage field calculation and analysis on power transformer, and based on the computation results, the radial stability experimental results of large capacity power transformer inner winding short-circuit model were compared to the simulation values to guide actual product analysis and checking. With the accumulated simulation experience on this model, then a type of sfz9-80MVA power transformer inner coil static and dynamic stability has been checked to confirm the radial instability phenomenon could whether or not occur on this product.

• Periodical: Advanced Materials Research (Volumes 986-987)
• Pages: 1926-1929
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.986-987.1926
• Online since: July 2014
• Authors: Xin Sun*, Yan Li, Fang Xu Han, Jian Li
• Keywords: Power Transformer, Radial Stability, Short-Circuit Electromagnetic Force

References

[1] Li HongChun. Method to Raise Short-Circuit Withstand Ability of Transformer. Transformer, 2006, 43(8): 1-4.

[2] Li Yan and so on. Winding Short Circuit Strength Calculation of 31500kVA Power Transformer. Transformer, 2007, 44(2): 8-13.

[3] Li HongKui, Li Yan. Axial Vibration Model Analysis of Transformer Windings under Different Levels of Pre-compression. Electric Machines and Control, 2010, 14(8): 98-102.

[4] Wang ShiShan, Li YanMing. Computation of Electrodynamic Force on Winding of Power Transformer. High Voltage Apparatus, 2002, 38(4): 22-25.

[5] Xin ZhaoHui and so on. Reasearch on Short Circuit Strength of Inner Winding of Large Transformer. Tansformer, 2009, 46(8): 39-42.

[6] Meng QinMing and so on. Simulation Research on Radial Stability of Internal Winding in Large Transformer. 2010, 47(4): 32-40.

[7] Chen YuHong and so on. Collection and analysis of Radial Simulated Signal of Short Circuit Vibration of Transformer Winding. Transformer, 2011, 48(4): 33-40.

[8] J.Y. Lee and so on. Finite Element Analysis of Short Circuit Electromagnetic Force in Power Transformer. 2009 12th International Conference on Electrical Machines and Systems (ICEMS 2009), Tokyo, (2009).

DOI: 10.1109/icems.2009.5382899

[9] Yinghao Zhu. Short Circuit Mechanical Force Withstand Capability Test. Transformer, 2001, 38(1): 1-7.

[10] Kumbhar, Ganesh B, Kulkarni S.V. Analysis of Short-circuit Performance of Split-winding Transformer Using Coupled Field-circuit Approach. IEEE Transactions on Power Delivery, 2007, 22(2): 936-943.

DOI: 10.1109/tpwrd.2007.893442
