HomeAdvanced Materials ResearchAdvanced Materials Research Vols. 986-987A Numerical Method for Ge-Profile of Microwave...

A Numerical Method for Ge-Profile of Microwave Power Device Based on Si/Si_1-x/Si

Abstract:

A double-mesa hetero-junction bipolar structure of NPN type microwave power device is used. The Si is chosen for emitter and collector, and Si_1-_xGe_x alloy is for base. Based on some experiment data, a numerical method is used to get an equation about forbidden band E_g via the variety composition of Ge at 300K using MATLAB, which is more precise than linearization. We also calculate the collector current density J_C via the variety of V_BE and the obtained equation is consistent with the experiment result. An optimum Ge composition value was found. It has practical significance for the device design and simulation.
