Effect of Milling Parameters on Surface Roughness for High-Speed Milling of Pre-Sintering Zirconia

Abstract:

Zirconia has been widely concerned in dental restoration duo to its excellent properties, but its high hardness make direct milling inefficient, while pre-sintering zirconia has good machinability. By single factor experiment in high-speed finish milling on 900°C pre-sintering zirconia, effect of four milling process parameters’ change on surface roughness was analyzed, and process sensitivity and relative sensitivity were put forward to compare the effect degree and to optimize milling parameters’ domains respectively. Roughness models are established on each parameter, and analysis results show the effect degree in order of spindle speed, feed engagement, cutting width, and cutting depth, spindle speed in them is a main factor. Based on relative sensitivity, milling parameters stability domain and instability domain are presented.

You might also be interested in these eBooks

Material, Mechanical and Manufacturing Engineering II

View Preview

Info:

Periodical:

Advanced Materials Research (Volume 988)

Pages:

253-256

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.988.253

Citation:

Cite this paper

Online since:

July 2014

Authors:

Jun Wei Liu*, Xiao Jun Yang

Keywords:

High-Speed Milling, Milling Parameters, Roughness, Sensitivity, Stability Domain

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] L. Yin, X.F. Song, and T. Huang, et al. International Journal of Machine Tools and Manufacture 46. 9 (2006) 1013-1026.

Google Scholar

[2] K. Kato, and C.S. Shyu. Machining of Semi-sintered Zirconia and Its Full-sintering for Final Shape. 2nd International Conference on Machining of Advanced Materials (MAM), Aachen, Germany, Sept. 30-Oct. 2, 1996, pp.427-434.

Google Scholar

[3] J.H. Song, and J.R.G. Evans. Journal of the European Ceramic Society 17. 14 (1997) 1665-1673.

Google Scholar

[4] X.B. Lei. Research on Key Techniques in High-speed Milling of Pre-sintered Zirconia Denture and Digital Oral Equipment. Nanjing University of Aeronautics and Astronautics, (2012). (In Chinese).

Google Scholar

[5] Weiwei Liu, Shuai Yang, and Yuan Cai. Aviation Precision Manufacturing Technology 48. 3 (2012) 5-9. (In Chinese).

Google Scholar
