Microstrain and Residual Stress in Thin-Films Made from Silver Nanoparticles Deposited by Inkjet-Printing Technology

Abstract:

Colloidal suspensions of nanoparticles are increasingly employed in the fabrication process of electronic devices using inkjet-printing technology and a consecutive thermal treatment. The evolution of internal stresses during the conversion of silver nanoparticle-based ink into a metallic thin-film by a thermal sintering process has been investigated by in-situ XRD using the sin²ψ method. Despite the CTE mismatch at the film/substrate interface, the residual stress in silver films (below 70 MPa) remains lower than in conventional PVD thin-films, as a result of the remaining porosity. A Warren-Averbach analysis further showed that the crystallite growth is associated with a minimization of the twin fault density and the elastic microstrain energy above 150°C. A stabilization of the microstructure and internal stress is observed above 300°C. Inkjet-printing technology thus appears as a good alternative to conventional metallization techniques and offers significant opportunities asset for interconnect and electronic packaging.

• Periodical: Advanced Materials Research (Volume 996)
• Pages: 930-935
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.996.930
• Online since: August 2014
• Authors: Romain Cauchois*, András Borbély, Patrice Gergaud, Mohamed Saadaoui, Karim Inal
• Keywords: Ag Nanoparticle, In Situ X-Ray Diffraction (XRD), Inkjet Printing (IJP), Polycrystalline Thin Films
