Experiment Research on Effect of Moving Flat Speed on Carding Force in Carding Machine

Abstract:

In order to research the influence of moving flat speed on carding force between cylinder and flat, the carding force test was carried out under the condition of seven level speeds of the flat with a specially developed dynamometer. Experimental results show that the flat speed has an obvious effect on the carding force, which on the first to tenth flats have been more influenced. The carding force increases as the flat speed rises. When the flat speed is 650 mm/min, the carding force is the largest. Raising the flat speed is equivalent to reducing load on the flat clothing surface. Therefore, average carding force increase on single fiber explains the basic reason that incremental flat speed results in the carding force raising. Cotton fibre carding process has been basically completed between the 14th and 20th flats.

• Periodical: Advanced Materials Research (Volumes 998-999)
• Pages: 418-421
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.998-999.418
• Online since: July 2014
• Authors: Ye Ping Zhao, Peng Zi Sun*, Xian Guo Han
• Keywords: Carding Force, Carding Machine, Flat Speed

References

[1] T. F. Shen, K. G. Xu, Study on carding force between cylinder and plate in a carding machine, Text. Technol. 3 (1964) 1-4, 37-40. (In Chinese).

[2] P. Artzt, O. Schreiber, Bestimmung und abhingig keiuen der kardierkraft an hochleiscung skarderbei produkrioncn uber 30 kg/h, Melliand Text. 4 (1974) 317-323.

[3] A. K. Sengupta, N. Vijayaraghavan, A. Singh, Studies on cylinder and flats in a card: part I- effect of machine variables on carding force, Indian J. Fibre Text. 8 (1983) 59-63.

[4] H. Song, J. Gao, F. S. He, Measurement and analysis on pulse carding force in the cylinder-plate zone of carding machine, J. N.W. Inst. Text. Sci. and Tech. 1 (1995) 19-22. (In Chinese).

[5] P. Artzt, Einfluss der kardierbreite auf die kardiertechnologie, Melliand Text. 5 (2006) 311-315.

[6] P. Z. Sun. Research and choice of flat speed of carding machine, Cott. Text. Technol. 35 (2007) 14-18. (In Chinese).

[7] H. Jungnitz, U. Heitmann, H. Planck, High quality yarn produced with card combing process, Melliand China. 5 (2010) 39-42. (In Chinese).

[8] D. P. Con, A. R. Kare, A new generation in carding technology. Text. Asia. 2/3 (2007) 52-57.

[9] B. S. Ma, Experiment of reducing short fibre in JC7. 3 tex silver, Carding Technol. 19 (2010) 48. (In Chinese).

[10] F. Xiao, Y. P. Zhao, X. G. Han, Development and application of carding force dynamometer, J. Eastern Liaoning Univ. (Nat. Sci. Ed. ). 19 (2012) 101-104. (In Chinese).
