An Islanding Detection Method for Photovoltaic Power Generation System Using Fluctuation Characteristic of PCC Harmonic Voltage

Abstract:

In the photovoltaic power generation system, the harmonic voltage of the point of common coupling (PCC) is determined by system disturbance, local load and photovoltaic power generation system itself together. Based on the fluctuations of this harmonic voltage, a new islanding detection method for the PV system is proposed. By extracting the higher harmonic components from the wavelet transformation of point of common coupling (PCC) voltage, and then taking its fluctuations as the islanding identification and detection index, non-detection zone (NDZ) can be eliminated, without a plus disturbance. According to IEEE Std.1547, simulated verification of the proposed method is accomplished in the ideal photovoltaic grid system. When the PCC voltage and frequency are within the normal range, it can not only give a fast and accurate detection to the occurrence of islanding, but also identify the false islanding, such as voltage dips and switching loads, effectively avoiding false detection caused by the false islanding.

You might also be interested in these eBooks

Advances in Applied Sciences, Engineering and Technology II

View Preview

Info:

Periodical:

Advanced Materials Research (Volumes 998-999)

Pages:

574-577

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.998-999.574

Citation:

Cite this paper

Online since:

July 2014

Authors:

Luo Yun*

Keywords:

False Islanding, Grid Connected, Harmonic Voltage, Islanding Detection, PV, Wavelet Transform (WT)

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] Liserre M, Pigazo A, Aquila A D, et al. An anti-islanding method for single-phase inverters based on a grid voltage sensor-less control [J]. IEEE Trans on Industrial Electronics, 2006, 53(5): 1418 -1426.

DOI: 10.1109/tie.2006.882003

Google Scholar

[2] IEEE Recommended Practice for Utility Interface of Photovoltaic (PV) Systems, IEEE Std. 929-2000, (2000).

Google Scholar

[3] T. Funabashi, K. Koyanagi and R. Yokoyama, A review of Islanding Detection Methods for Distributed Resources, in Proceedings of 2003 IEEE Bologna Power-Tech Conference, June 23-26, Bologna, Italy, p.6.

DOI: 10.1109/ptc.2003.1304617

Google Scholar
