Sensor Assisted Closed-Loop Conformal Printing of Electronics Using Multiaxis Additive Manufacturing

Abstract:

Additive Manufacturing is a promising technology for making electronics with complex geometry shapes. However, they typically need to be printed on conformal surfaces and are highly sensitive to imperfections on the surfaces. Both challenges, unfortunately, can’t be met with the current technology. The main cause is the open loop control in today’s AM practices. In this paper, we demonstrate a technology prototype that uses sensor assistance to create an end-to-end closed-loop additive manufacturing capability for making RF electronics. We show how a displacement sensor can be incorporated into a nScrypt 3DX-700 multiaxis printer, and scan in-situ the conformal surfaces and previously existing imperfections. The in-situ scanning’s results are then used to adjust future printing operations. The evaluation with several benchmark models shows that our technology can successfully manufacture RF electronic devices conforming to the design specifications.

• Periodical: Advances in Science and Technology (Volume 157)
• Pages: 85-92
• DOI: https://doi.org/10.4028/p-7mKQnp
• Online since: September 2024
• Authors: Khang Tran, Tyler Rizak, Colin Bonner, Uyen Nguyen, Mark Mirotznik, Xiaoming Li*
• Keywords: Additive Manufacturing of Electronics, Conformal Printing, Multiaxis Printing, Sensor Assisted Closed-Loop

References

[1] S. Biswas and M. Mirotznik, "High gain, wide-angle QCTO-enabled modified Luneburg lens antenna with broadband anti-reflective layer", Nature Scientific Reports, Vol. 10, No. 1, 1-13, 2020.

DOI: 10.1038/s41598-020-69631-6

[2] K. McParland, Z. Larimore, P. Parsons, A. Good, J. Suarez and M.S. Mirotznik, "Additive Manufacture of Custom Radiofrequency Connectors", IEEE Transactions on Components, Packaging and Manufacturing Technology, Vol. 12, No. 1, Jan. 2022, pp.168-173.

DOI: 10.1109/tcpmt.2021.3134603

[3] K. McParland and M.S. Mirotznik, "Design and Additive Manufacture of Multi-Tapered Coaxial Baluns", IEEE Transactions on Components, Packaging and Manufacturing Technology, Vol. 12, No. 11, November 2022, pp.1806-1815.

DOI: 10.1109/tcpmt.2022.3222444

[4] E. Gupta, C. Bonner, N. Lazarus, M.S. Mirotznik and K. Nicholson "Multi-axis Manufacture of Conformal Metasurface Antennas", IEEE Antennas and Wireless Propagation Letters, June 2023, pp.1-5.

DOI: 10.1109/lawp.2023.3282556

[5] Xiaoming Li, Yulin Zhang."G-Code Re-compilation and Optimization for Faster 3D Printing".  The 33rd Workshop on Languages and Compilers for Parallel Computing (LCPC), Stony Brook, NY, USA. October, (2020)

DOI: 10.1007/978-3-030-95953-1_8
